20M Armored Fiber Patch Cord LC to LC Duplex SM 9/125 Single Mode Cable
✨ PRODUCT OVERVIEWThis 20M Armored LC-LC Duplex Single Mode Fiber Patch Cord (9/125μm) is engineered for high-speed, long-distance data transmission in harsh and high-traffic environments. The stainless steel armored layer delivers heavy-duty protection against crushing, bending, rodent damage, and daily wear, making it perfect for data centers, telecom rooms, industrial networks, and indoor/outdoor deployments. Equipped with LC-LC duplex connectors and single-mode fiber, it ensures stable performance, seamlessly connecting switches, SFP/SFP+ transceivers, patch panels, and other fiber optic equipment—ideal for both professional and industrial use.

🔥 KEY FEATURES

• ✅ Armored Heavy-Duty Protection - Stainless steel armored jacket + durable LSZH/PVC outer layer resists crush, twist, rodent bites, and environmental damage—ideal for exposed or high-traffic routing (no need for extra protection sleeves).
• ✅ LC-LC Duplex UPC Connectors - Precision zirconia ferrules, low insertion loss (≤0.3dB), high return loss (≥50dB), ensuring seamless connection with SFP/SFP+ transceivers, switches, and patch panels.
• ✅ 20M (65.6ft) Single Mode 9/125μm - Standard SM fiber optimized for 1310nm/1550nm wavelengths, supports up to 10Gbps transmission, perfect for long-distance patching between racks, rooms, or buildings.
• ✅ 10Gbps High-Speed Performance - suitable for data center interconnects, enterprise LAN/WAN, and high-bandwidth industrial applications.
• ✅Durable & Reliable - Wide operating temperature range (-20°C ~ +70°C), RoHS compliant, resistant to moisture and corrosion—built for long-term use in harsh environments.
• ✅ 100% Factory Tested - Each patch cord undergoes strict insertion loss and return loss testing before shipment, guaranteeing consistent performance and no signal loss.

📋 FULL SPECIFICATIONS

• Connector: LC to LC (Duplex), UPC Polish
• Fiber Type: Single Mode (SM) 9/125μm
• Length: 20 Meters / 65.6 Feet
• Cable OD: 3.0mm
• Cable Type: Armored (Stainless Steel Layer)
• Insertion Loss: ≤0.3dB
• Return Loss: ≥50dB
• Operating Wavelength: 1310nm / 1550nm
• Operating Temperature: -20°C ~ +70°C
• Jacket Material: LSZH / PVC
• Compliance: RoHS, TIA/EIA 604, IEC 60793-2-10

📌 APPLICATIONS

• Data Center Interconnect & Rack-to-Rack Patching
• Telecom & Enterprise LAN/WAN Networks
• Industrial & Harsh Environment Wiring (exposed routes)
• SFP/SFP+ Transceiver Connections
• Patch Panel & Fiber Cabinet Cabling
• Long-Distance Indoor/Outdoor Fiber Patching
• Security Camera & High-Bandwidth Equipment Connections

🛡️ PACKAGE INCLUDED1 x 20M Armored LC-LC Duplex Single Mode Fiber Patch Cord (9/125μm)

🔔 NOTE: If you need custom lengths (10M, 20M, 30M, 100M) or different connector combinations, contact us—we offer custom solutions to fit your needs .
