ADT R33 & K33 Series PCI-E X16 Signal Connection Cable

Brand: ADTModel: R33 Series, K33 Series (K33VS, K33NS, K33FF etc.)
Bandwidth: PCIe 4.0 x16 (Gen4), up to 256Gbps
Cable Length: 5cm ~ 100cm, custom length available. Custom length has different pricing, please contact customer service to revise price before payment.

⚠️ Important Purchase Restriction: This product is only for purchase specified by professional engineers. Not suitable for general use. General buyers please DO NOT place orders.

Model Specification Table (R33 Series)ModelGold Finger & Connector DirectionTx-Rx SignalR33SSx16 Straight Male Gold Finger to x16 Straight Male Gold FingerStraight Signal Pass-throughR33FFx16 Straight Female Connector to x16 Straight Female ConnectorStraight Signal Pass-throughR33LRx16 Up-angle Female Connector to x16 Up-angle Female Connector, Dual Up BendStraight Signal Pass-throughR33NSx16 Straight Male Gold Finger to x16 Straight Male Gold FingerCross Signal ExchangeR33NFx16 Straight Male Gold Finger to x16 Straight Female ConnectorCross Signal ExchangeR33NLx16 Straight Male Gold Finger to x16 Up-angle Female ConnectorCross Signal ExchangeR33NRx16 Straight Male Gold Finger to x16 Down-angle Female ConnectorCross Signal ExchangeR33VFx16 Straight Female Connector to x16 Straight Female ConnectorCross Signal ExchangeK33VS4.0 x16 Straight Male Gold Finger to x16 Straight Male Gold FingerStraight Signal Pass-throughK33FF4.0 x16 Straight Female Connector to x16 Straight Female ConnectorStraight Signal Pass-throughK33NS4.0 x16 Straight Male Gold Finger to x16 Straight Male Gold FingerCross Signal ExchangeMain Parameter Comparison BandwidthPCIe 3.0 x16PCIe 3.0 x16PCIe 3.0 x16PCIe 4.0 x16PCIe 4.0 x16Cable SpecificationGen3 6Px6Gen3 6Px6Gen3 6Px6Gen5 6Px7Gen5 6Px7Cable ShieldNoNoNoYesYesCable ConductorTinned CopperTinned CopperTinned CopperSilver Plated CopperSilver Plated CopperJacket Impedance95 Ω95 Ω95 Ω85 Ω85 ΩConnector ColorBlackBlackBlackSilverSilverMax Current75W75W75W75W75WPin CompatibilityPCIe x16 edgePCIe x16 edge & connPCIe x16 connPCIe x16 edge & connPCIe x16 edge & connSignal ModeTX-TX Straight PassTX-RX Cross ExchangeTX-RX Cross ExchangeTX-RX Cross ExchangeCLKRUN#, WAKE#, SMBUS, JTAG1~5TX-TX Straight PassCLKRUN#, WAKE#, SMBUS, JTAG1~5CertificationRoHS, ULRoHS, ULRoHS, ULRoHS, CE, FCC, ULRoHS, CE, FCC, ULScrew SpacingN/A10.8cm10.8cmN/A10.8cmGold Plating MaterialFiberglass BoardFiberglass BoardFiberglass BoardAluminum AlloyAluminum AlloyProduct Advantages

1. High-performance Shielded CableADT self-developed 5th generation shielded high-speed cable, equipped with premium connectors. Stable high-frequency transmission for PCIe 4.0.
2. Customizable Length & Stable High SpeedCustom length available from 3cm up to 100cm. Low impedance design. Stable full-speed PCIe4.0 performance within 60cm cable length.
3. Differential Signal Via-less PCB DesignNo parasitic capacitance or inductance that causes signal attenuation and interference. Avoid CAF micro-short circuit issue for longer service life.
4. High TG High-frequency Low-resistance PCBPrecision PCB with high TG substrate. Copper thickness upgraded to 1oz. Gold fingers with sufficient gold plating for excellent conductivity. Reduce system crash and audio distortion caused by oxidation and rising impedance.
5. Heavy-duty Anti-break Structure3mm PCB aluminum shim protection at soldering joints. Tensile resistant, anti-interference, prevents wire break and pin drop.
6. Low-profile & Widened PCB DesignLow-profile design will NOT block graphics cards. Widened & lengthened PCB for easier installation and lower damage risk.

Cable Specification

• Shielding: Equipped with metal layer shielding, adopting advanced EMI shielding conductive polymer. Flat ribbon cable design. The conductive polymer fully covers each cable for complete EMI shielding, blocks incoming and outgoing electromagnetic emission. Minimize interference and performance degradation while reducing cable weight.
• Cable Thickness: 1.3mm
• Flexibility: Soft flat cable, bendable without affecting signal performance.

⚠️ Installation & Purchase Warnings

1. Orientation Check Before Plugging: Please confirm direction carefully. Reverse or offset insertion may burn your equipment. Hold the device socket firmly when plugging, avoid excessive force breaking socket pins.DO NOT bend or pull the cable within 2cm range of soldering joints on both cable ends.
2. Signal Loss Disclaimer: Different motherboards and hardware have different signal driving capability. Our internal test results may differ from your actual test. Signal loss is unavoidable with extension cables. Please DO NOT purchase if you require zero signal loss.
3. Device Compatibility: GPUs and motherboards will age and oxidize over time. Using extension cables on aged hardware will reduce stability.NOT compatible with equipment older than 4 years. Do not purchase for old devices.
4. Application Restriction: Reserved for product engineer specified purchase, only for product testing purposes. Not permitted for other applications.

Quality Control

Direct sale from ADT factory. 100% full power-on inspection before shipment.
