Learn more about ASUS PRIME H610M-A D4-CSMModelBrandASUSModelPRIME H610M-A D4-CSMSupported CPUCPU Socket TypeLGA 1700* Dedicated LGA1700 mounting bracket is required.CPU TypeSupports 13th / 12th Gen Intel Core Processors, Pentium Gold and Celeron Processors*
*May require a BIOS update to boot the 13th gen Intel® Core™ desktop processors. Visit: Refer to www.asus.com for CPU support list.Supported CPU TechnologiesSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.ChipsetsChipsetIntel H610Onboard VideoOnboard Video ChipsetSupported only by CPU with integrated graphicMemoryNumber of Memory Slots2x288pin (DDR4)Memory StandardDDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 ** Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).Maximum Memory Supported64GBChannel SupportedDual ChannelExpansion SlotsPCI Express 4.0 x161 x PCI Express 4.0 x16* Actual support may vary by CPU.PCI Express x11 x PCI Express 3.0 x1Storage DevicesSATA 6Gb/s4 x SATA 6Gb/sM.2M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x2 mode)Onboard AudioAudio ChipsetRealtek 7.1 Surround Sound High Definition Audio CODEC** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.Audio Channels7.1 ChannelsOnboard LANLAN ChipsetIntel 1Gb EthernetMax LAN Speed1GbpsRear Panel PortsBack I/O Ports2 x USB 3.2 Gen 2 ports (2 x Type-A)4 x USB 2.0 ports (4 x Type-A) 1 x DisplayPort1 x HDMI port1 x D-Sub port1 x V-M.2 slot (Key E)1 x Intel 1Gb Ethernet port3 x Audio jacks 1 x PS/2 Keyboard (purple) port1 x PS/2 Mouse (green) portInternal I/O ConnectorsOnboard USB1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 3 USB 2.0 portsOther ConnectorsFan and Cooling related 1 x 4-pin CPU Fan header2 x 4-pin Chassis Fan headersMiscellaneous3 x Addressable Gen 2 headers2 x AURA RGB headers1 x Clear CMOS header1 x Front Panel Audio header (AAFP) 1 x COM Port header1 x S/PDIF Out header1 x Speaker header1 x SPI TPM header (14-1pin)1 x 10-1 pin System Panel headerPhysical SpecForm FactorMicro ATXLED LightingRGBDimensions (W x L)9.6" x 8.3"Power Pin1 x 24-pin Main Power connector1 x 8-pin +12V Power connectorWindows CompatibilityWindows 11SupportedFeaturesFeaturesSpecial Features:ASUS 5X PROTECTION III- DIGI+ VRM- LANGuard- Overvoltage Protection- SafeSlot Core - Stainless-Steel Back I/OASUS Q-Design - Q-DIMM- Q-SlotASUS Thermal Solution- VRM heatsink designAURA Sync- AURA RGB headers- Addressable Gen 2 headersSoftware Features:ASUS Exclusive SoftwareArmoury Crate- AURA Creator- AURA Sync- Fan Xpert 2+AI Suite 3- Performance And Power Saving UtilityTurboV EVOEPU DIGI+ VRMASUS CPU-ZNorton Anti-virus software (Free Trial version) WinRARUEFI BIOSASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ ModeBIOS:128 Mb Flash ROM, UEFI AMI BIOSManageability:WOL by PME, PXE Operating System:Windows 11 64-bit, Windows 10 64-bitPackagingPackage ContentsAccessories:Cables2 x SATA 6Gb/s cables Miscellaneous1 x I/O Shield 1 x M.2 SSD screw packageInstallation Media1 x Support DVDDocumentation1 x User guideShippingEnjoy fast and reliable shipping when you buy your products from Newegg. Our ordering and shipping services are among the best in the industry due to short processing times and a variety of shipping methods. Your orders are packaged at one of the many local warehouses across the country, minimizing delivery times and ensuring you get your purchases as soon as possible.PaymentsNewegg has partnered with PayPal to offer you the very best in payment services. PayPal allows you to buy with confidence, knowing your payments are processed quickly and securely with state-of-the-art encryption technology.ReturnReturns are subject to restocking fees of 15% - 30% of the purchase price and return shipping fees. For products that are eligible for return for replacement, the return shipping labels are free for returns for replacement of the same item within the applicable return policy period. Newegg does NOT charge for restocking fees or return shipping labels for returns of defective products, or if you received the wrong product, the product did not match what was shown on the Site, or we made some other shipping error, provided the item is returned within its return policy period, and in accordance with the Return Policy. For international buyers, items shipped internationally do not qualify for manufacturer warranties.
