N/A

IOS-XE 3.07

ipbase

2x PWR-C1-350WAC (Takes C13 Plug)

Minor signs of prior use, including scratches
scuffs and possible adhesive residue remaining.

Power Cord(s)

Switch#show diagnostic result switch 1Current bootup diagnostic level: minimalswitch 1: SerialNo : FCW2102F1S0 Overall Diagnostic Result for switch 1 : PASS
Diagnostic level at card bootup: minimal Test results: (. = Pass, F = Fail, U = Untested) 1) DiagGoldPktTest: Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
U U U U U U U U U U U U U U U U U U U U U U U U Port 25 26 27 28 29 30 31 32
----------------------------
U U U U U U U U
2) DiagThermalTest -----------------> .
3) DiagFanTest ---------------------> .
4) DiagPhyLoopbackTest: Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
U U U U U U U U U U U U U U U U U U U U U U U U Port 25 26 27 28 29 30 31 32
----------------------------
U U U U U U U U
5) DiagScratchRegisterTest ---------> .
6) DiagStackCableTest --------------> U
7) DiagMemoryTest ------------------> U
Switch#show env all
Switch 1 FAN 1 is OK
Switch 1 FAN 2 is OK
Switch 1 FAN 3 is OK
FAN PS-1 is OK
FAN PS-2 is OK
Switch 1: SYSTEM TEMPERATURE is OK
SW PID Serial# Status Sys Pwr PoE Pwr Watts
-- ------------------ ---------- --------------- ------- ------- -----
1A PWR-C1-350WAC ART2102F4HW OK Good Good 350
1B PWR-C1-350WAC ART2102F4QE OK Good Good 350Switch#show inv
NAME: "c38xx Stack", DESCR: "c38xx Stack"
PID: WS-C3850-24T , VID: V07 , SN: FCW2102F1S0NAME: "Switch 1", DESCR: "WS-C3850-24T-S"
PID: WS-C3850-24T-S , VID: V07 , SN: FCW2102F1S0NAME: "Switch 1 - Power Supply A", DESCR: "Switch 1 - Power Supply A"
PID: PWR-C1-350WAC , VID: V02 , SN: ART2102F4HWNAME: "Switch 1 - Power Supply B", DESCR: "Switch 1 - Power Supply B"
PID: PWR-C1-350WAC , VID: V02 , SN: ART2102F4QENAME: "Switch 1 FRU Uplink Module 1", DESCR: "4x1G Uplink Module"
PID: C9300-NM-4G , VID: V01 , SN: FOC21491KHW
Switch#show post
Stored system POST messages:Switch 1
---------
POST: CRYPTO Tests : Begin
POST: CRYPTO Tests : End, Status PassedPOST: PHY Loopback: loopback Test : Begin
POST: PHY Loopback: loopback Test : End, Status PassedPOST: Thermal, Temperature Tests : Begin
POST: Thermal, Temperature Tests : End, Status PassedPOST: Thermal, Fan Tests : Begin
POST: Thermal, Fan Tests : End, Status PassedPOST: SIF Tests : Begin
POST: SIF Tests : End, Status PassedSwitch#show int statusPort Name Status Vlan Duplex Speed Type
Gi1/0/1 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/2 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/3 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/4 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/5 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/6 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/7 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/8 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/9 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/10 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/11 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/12 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/13 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/14 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/15 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/16 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/17 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/18 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/19 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/20 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/21 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/22 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/23 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/24 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/1/1 notconnect 1 auto auto unknown
Gi1/1/2 notconnect 1 auto auto unknown
Gi1/1/3 notconnect 1 auto auto unknown
Gi1/1/4 notconnect 1 auto auto unknown
Switch#show pow iModule Available Used Remaining
(Watts) (Watts) (Watts)
------ --------- -------- ---------
1 n/a n/a n/a
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----
Switch#show module
Switch Ports Model Serial No. MAC address Hw Ver. Sw Ver.
------ ----- --------- ----------- -------------- ------- --------
1 32 WS-C3850-24T-S FCW2102F1S0 2c31.24b9.e380 V07 03.07.05ESwitch#show license right-to-use
Slot# License name Type Count Period ipbase permanent N/A LifetimeLicense Level on Reboot: ipbase
Switch#show ver
Cisco IOS Software, IOS-XE Software, Catalyst L3 Switch Software (CAT3K_CAA-UNIVERSALK9-M), Version 03.07.05E RELEASE SOFTWARE (fc1)
Technical Support: (c) 1986-2017 by Cisco Systems, Inc.
Compiled Fri 10-Feb-17 07:59 by prod_rel_teamCisco IOS-XE software, Copyright (c) 2005-2015 by cisco Systems, Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version For more details, see the
documentation or "License Notice" file accompanying the IOS-XE software,
or the applicable URL provided on the flyer accompanying the IOS-XE
software.ROM: IOS-XE ROMMON
BOOTLDR: CAT3K_CAA Boot Loader (CAT3K_CAA-HBOOT-M) Version 3.58, RELEASE SOFTWARE (P)Switch uptime is 1 minute
Uptime for this control processor is 4 minutes
System returned to ROM by reload
System image file is "flash:packages.conf"
Last reload reason: Reload commandThis product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.A summary of U.S. laws governing Cisco cryptographic products may be found you require further assistance please contact us by sending email to
(email)License Level: Ipbase
License Type: Permanent
Next reload license Level: Ipbasecisco WS-C3850-24T (MIPS) processor with 4194304K bytes of physical memory.
Processor board ID FCW2102F1S0
1 Virtual Ethernet interface
28 Gigabit Ethernet interfaces
4 Ten Gigabit Ethernet interfaces
2048K bytes of non-volatile configuration memory.
4194304K bytes of physical memory.
252000K bytes of Crash Files at crashinfo:.
1611414K bytes of Flash at flash:.
0K bytes of Dummy USB Flash at usbflash0:.
0K bytes of at webui:.Base Ethernet MAC Address : 2c:31:24:b9:e3:80
Motherboard Assembly Number : 73-16297-05
Motherboard Serial Number : FOC21016KA6
Model Revision Number : AB0
Motherboard Revision Number : A0
Model Number : WS-C3850-24T
System Serial Number : FCW2102F1S0
Switch Ports Model SW Version SW Image Mode
------ ----- ----- ---------- ---------- ----
* 1 32 WS-C3850-24T 03.07.05E cat3k_caa-universalk9 INSTALL
Configuration register is 0x102
