HPE ProLiant DL360 DL365 Gen10+Plus 8SFF x4 Tri-Mode 24G U.3 BC Backplane KitThis listing is for 1 (one) HPE DL360 DL365 Gen10 Plus 8SFF x4 Tri-Mode U.3 NVMe BC BP Kit 26429-B21We can integrate this in a full solution, please contact usContents:8x SFF U.3 Tri-mode x4 backplane (DL325, DL360, DL365)1x Signal Cable Port 1A/Port 2A to Port 3 and Port 41x Signal Cable Port 1B/ Port 2b to Port 1 and Port 2Power cable is not includedPlease contact us with any questionsThank youISLOC: OFC-ST-R1-S6This listing is for one HPE DL360 Gen11 2SFF x4 Tri-Mode U.3 NVMe BC BP Kit 26429-B21
We can integrate this in a full solution, please contact us
Contents:2x SFF U.3 Tri-mode x4 backplane1x Signal Cable MB Port 1 to 2SFF BP1x Signal Cable Port 11 to 2SFF BP1x Signal Cable 2 SFF backplane to System board SlimSAS port 11x Power cable
Notes:− Supports SATA, SAS and NVMe Basic Carrier (BC) drives.− NVMe SSDs must be U.3. P48896-B21 P48899-B21− Supports NVMe Direct Access and slotted Tri-Mode controllers.− Includes Direct Access cables and backplane power cables. Drive cages will be connected to Motherboard (Direct Attach) if no Internal controller is selected. Direct Attach is capable of supporting all the drives (SATA or NVMe).− Mixing SR and MR internal controllers is not allowed.− Requires 8 SFF cables (P48909-B21 HPE ProLiant DL360 Gen11 8 SFF PCIe Controller Cable Kit) for Tri-Mode PCIe standup controllers.− Requires 8 SFF cables (P52416-B21 HPE ProLiant DL360 Gen11 OROC Tri-Mode Cable Kit) for OCP3.0 controllers.− Requires 2 SFF cables (P48910-B21 HPE ProLiant DL360 Gen11 2 SFF Tri-Mode Controller Cable Kit) for Tri-Mode PCIe standup and OCP3.0 controllers.− Max 1 of 8 SFF Drive cage can be selected per server.− If 8 SFF drive cage is selected without 2 SFF Drive cage, then Max 1 of the internal controller can be selected.− If 2 SFF drive cage is selected, then 8 SFF Drive cage must be selected.− If 8 SFF x4 drive cage is connected to Direct Attach (without internal controller and 8 SFF cable), then only NVMe drive can be selected in this drive cage.− If 2 SFF U.3 drive cage is connected to Direct Attach (without internal controller and 2 SFF cable), then either SATA or NVMe drive can be selected in this drive cage.− For 2 SFF U.3 drive cage selection in 1 Processor configuration: If 2 SFF Drive cage is connected to Direct Attach (without Internal controller and 2 SFF cable) and NVMe drive is selected, then "CPU1 to OCP2 x8" and "OCP1 x16" OCP upgrade kit cannot be selected.
Please contact us with any questions
Thank you
LOC: OFC-ST-R8-S2
