Warm Tips

1. Please do usegenuinebrand RAM, this motherboard can't work with fake RAM.2. If the motherboard can't run correctly, please first check your CPU whether can be compatible with our motherboard.3. Most of "can't boot" problem was caused by RAM, please don't use "single side" RAM.Sepcifiction

CPU

•4th Generation Intel® Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® processors for LGA 1150 socket
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Chipset

• Intel® Z87 Express Chipset

Main Memory

• Support four DDR3 MHz DRAM, 32GB Max
- Dual channel memory architecture
- Supports Intel® Extreme Memory Profile (XMP)
- Supports non-ECC, un-buffered memory

Slots

•3 x PCIe 3.0 x16 slots (support x16, x8/x8, x8/x4/x4 modes)
• 4 x PCIe 2.0 x1 slots

On-Board SATA

• SATAIII controller integrated in Intel®Z87 chipset
- 1 x mSATA 6Gb/s port*
- Supports six SATAIII ports (SATA1~6) by Z87
- Up to 6Gb/s transfer speed.

• SATAIII controller integrated in ASMedia®ASM1061 chipset
- Up to 6Gb/s transfer speed.
- Supports two SATA ports (SATA7~8) by ASM1061
* The SATA6 port will be unavailable whena SSD installed in the mSATA port.
** Supports Intel Core processors on Windows 7 and Windows 8.

• RAID
- SATA1~6 ports support Intel Rapid Storage Technology enterprise (AHCI / RAID 0/1/5/10) by Intel Z87

USB

•6 x USB 3.0 ports (4 ports on the back panel, 2 ports available through the internal USB connectors)
•8 x USB 2.0 ports (2 ports on the back panel, 6 ports available through the internal USB connectors*)
*internal JUSB1 connector supports MSI Super Charger

Audio

• Realtek® ALC1150 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output

LAN

• 1x Killer E2205 Gigabit LAN controller*
* The Killer Network Manager is only available for Windows 7 and Windows 8 currently. The supported drivers for other operating systems would be available on the website if provided by vendor.

Multi-GPU

• Supports ATI® CrossFire™ Technology
• Supports NVIDIA® SLI™ Technology
* Supports Windows 7 and Windows 8.

Internal I/O Connectors

- ATX 24-Pin power connector
- 8-pin ATX 12V power connector
- 8 x SATA 6Gb/s connectors
- 1 x mSATA port
- 3 x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
- 1 x USB 3.0 connector (supports additional 2 USB 3.0 ports)
- 2 x 4-pin CPU fan connectors
-3 x 4-pin system fan connectors
- 1 x Multi BIOS Switch
- 1 x Trusted Platform Module (TPM) header
- 1 x Serial port connector
- 1 x Front Panel Audio connector
-2 x System panel connectors
- 1 x Chassis Intrusion connector
- 1 x V-Check Points Set (7x V-Check connectors)
- 1 x GO2BIOS button
- 1 x Power button
- 1 x OC Genie button
- 1 xResetbutton
- 1 x Clear CMOS jumper
- 1 x 2-Digit Debug Code LED

Back Panel I/O Ports

- 1 x PS/2 keyboard/mousecombo port
- 1 x Clear CMOS button
- 1 x Coaxial S/PDIF-outport
- 1 x Optical S/PDIF-outport
-2 x USB 2.0ports
-4 x USB 3.0ports
- 1 x RJ45 LANjack
- 6 OFC audio jacks
- 1 x VGA port, supporting a maximum resolution of 1920x1200 at 60Hz, 24bpp
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200 at 60Hz, 24bpp
- 1 x HDMI port, supporting a maximum resolution of 4096x2160 at 24Hz, 24bpp/ 2560x1600at60Hz, 24bpp/ 1920x1080a60Hz, 36bpp

BIOS

• The motherboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
• The motherboard provides a Desktop Management Interface(DMI) function which records your motherboard specifications.

Dimension

• 12 in. x 9.6 in. (30.4 cm x 24.4 cm) ATX Form Factor

Mounting

• 9 mounting holes.

AccessoriesPlease note only the following accessories come with the mobo:

• 1 x motherboard
• 2 x SATA cables
• 1 x I/O back panel
