Key Features - IoT Edge Computing
- DVR / NVR
- Machine Automation
- Digital Signage
- Medical Applications
- IoT Gateway
1. Single Socket H4 (LGA 1151) supports:
8th/9th Gen Intel® Core™ i7/i5/i3
/ Pentium® / Celeron® processor2. Intel® Q370 chipset3. 2 Internal 2.5" drive bays (Top drive
bay area can accommodate either an
AOC with riser card and bracket or
2.5" drive on the top bracket.)4. Up to 32GB unbuf. non-ECC SO-DIMM,
DDR4-2666Mz; in 2 DIMM slots5. 1 PCI-E 3.0 x16 LP AOC slot, M.2 M key:
PCI-E 3.0 x4, support 2242/2280;
M.2 E KEY: PCI-E 3.0 x1, support 22306. 2x 1GbE LAN ports7. 4 USB 3.1 (2 type A and 2 type C)8. 1 HDMI, 1 DP, 1 DVI-D, HD Audio9. 2x 4cm high performance PWM fans10. DC Power Adapter
