About this item

• JD Power Award ---Highest in customer satisfaction for wireless routers 2017 and 2019
• Wi-Fi 6 Router: Archer AX10 comes equipped with latest wireless technology WiFi6 featuring OFDMA 1024-QAM, drastically increasing the speed and efficiency of the entire network.
• Next-gen Dual Band router – 300 Mbps on 2. 4 GHz (802. 11n) + 1201 Mbps on 5 GHz (802. 11ax)
• Connect more devices than ever before Wi-Fi 6 technology simultaneously communicates more data to more devices using OFDMA and MU-MIMO while reducing lag dramatically
• Triple-core processing the 1. 5 GHz tri-core processor ensures communications between your router and all connected devices are smooth and Buffer-Free
• More coverage with less interference achieve the strongest most reliable Wi-Fi coverage with Archer AX10 As it focuses signal strength to your devices using Beamforming technology.
• Backward compatible Archer AX10 supports all previous 802. 11 standards and all Wi-Fi devices
• Easy setup set up your internet router in minutes with the powerful TP-Link tether app. Compatible with 11a/b/g/n/ac Wi-Fi standards. System Requirements-Microsoft Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux, Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other, Java-enabled browser, Cable or DSL Modem. Wireless Functions-Enable/Disable Wireless Radio, WMM

WIRELESSStandardsWi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHzWiFi SpeedsAX1500
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 300 Mbps (802.11n)WiFi Range2-3 Bedroom Houses4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas

Beamforming
Concentrates wireless signal strength towards clients to expand WiFi rangeWiFi CapacityHighDual-Band
Allocate devices to different bands for optimal performance

OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients

Airtime Fairness
Improves network efficiency by limiting excessive occupation

4 Streams
Connect your devices to more bandwidthWorking ModesRouter Mode
Access Point ModeSECURITYNetwork SecuritySPI Firewall
Access Control
IP & MAC Binding
Application Layer GatewayGuest Network1× 5 GHz Guest Network
1× 2.4 GHz Guest NetworkVPN ServerOpenVPN
PPTPWiFi EncryptionWPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x)HARDWAREProcessor1.5 GHz Triple-Core CPUEthernet Ports1× Gigabit WAN Port
4× Gigabit LAN PortsButtonsWPS/Wi-Fi Button
Power On/Off Button
Reset ButtonPower12 V ⎓ 1 ASOFTWAREProtocolsIPv4
IPv6OneMesh™OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
EasyMeshMesh networking creates smooth, fast, stable roaming. Archer AX10 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.
Parental ControlsURL Filtering
Time ControlsWAN TypesDynamic IP
Static IP
PPPoE
PPTP
L2TPQuality of ServiceQoS by DeviceCloud ServiceAuto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNSNAT ForwardingPort Forwarding
Port Triggering
DMZ
UPnPIPTVIGMP Proxy
IGMP Snooping
Bridge
Tag VLANDHCPAddress Reservation
DHCP Client List
ServerDDNSTP-Link
NO-IP
DynDNSManagementTether App
Webpage
OTHERSystem RequirementsInternet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensingTEST DATAWiFi Transmission PowerFCC:
<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz)WiFi Reception Sensitivity5 GHz:
11a 6Mbps:-97dBm
11a 54Mbps:-79dBm
11ac VHT20_MCS0:-96dBm
11ac VHT20_MCS11:-66dBm
11ac VHT40_MCS0:-94dBm
11ac VHT40_MCS11:-63dBm
11ac VHT80_MCS0:-91dBm
11ac VHT80_MCS11:-60dBm
11ax HE20_MCS0:-95dBm
11ax HE20_MCS11:-63dBm
11ax HE40_MCS0:-92dBm
11ax HE40_MCS11:-60dBm
11ax HE80_MCS0:-89dBm
11ax HE80_MCS11:-58dBm
2.4 GHz:
11g 6Mbps:-91dBm
11a 54Mbps:-74dBm
11n HT20_MCS0:-90dBm
11n HT20_MCS7:-73dBm
11n HT40_MCS0:-88dBm
11n HT40_MCS7:-70dBm
PHYSICALDimensions (W×D×H)10.2 × 5.3 ×1.5 in
(260.2 × 135.0 × 38.6 mm)Package ContentsWi-Fi Router Archer AX10
Power Adapter
RJ45 Ethernet Cable
