Wavlink Upgraded Wi-Fi 6E AX5400 Tri-band Wi-Fi Module with Bluetooth 5.3--Ascending to Greater Heights!

Product Overview
Wavlink Wi-Fi 6E Tri-band M.2 module(WL-WN675X3M) is an AX5400 wireless adapter for laptops that
has the NGFF/M.2 connector. The wireless adapter supports MU-MIMO, 1024-QAM, OFDMA, helps you to
get a stable and high-speed wireless signal by cooperating with a wifi6/wifi 6e router. Compliant with 802.11 ax specification,
the module supports 2.4GHz, 5GHz and 6GHz bands. In addition, combined with WPA3 security and Bluetooth 5.3,
the Wi-Fi 6E network card equips your PC with all the latest, future-proof technology.

Compatible OS
Support Windows 10/11 64-bit, Linux 5.10+
*Please note that to utilize 6GHz band, the user must be on Windows 11 version.

MU-MIMO Supported
MU-MIMO technology effectively improves signal gain when multiple users are sending and receiving
at the same time and then minimized lag for your PC.

WPA3 Security
With the introduction of WPA3, cyber security is boosted with new capabilities.
Ensuring that your home network is fortified with superior level of Model: WN675X3M
Chipset: Intel AX210NGW
Transmission Rate: 2.4GHz: 574Mbps 5GHz: 2400Mbps 6GHz: 2400Mbps
Protocol Standard: support IEEE 802.11a/b/g/n/ac/ax
Frequency Band: 2.4GHz, 5GHz, 6GHz
Technical Support: MU-MIMO,OFDMA, BSS Coloring, 1024QAM, Target Wake Time(TWT)
Bus Interface: M.2/NGFF Key-A or Key-E
Package Size: 22mm x 30mm (0.9in x 1.2in )
Support System: Win 11/10 (64 bit), Linux 5.10+
Bluetooth Version: Bluetooth 5.3
Wireless Security: WPA/ WPA2/ WPA3, WPA-PSK/ WPA2-PSK Encryption

Package Contents:
-1x WiFi 6E AX5400 M.2 Module
-1x Screwdriver+Screw
-1x User Manual

Knowing the following will give you a better product experience:
1. This laptop wifi card is available for laptops with an M.2 slot (key A or E).
2. Download the driver from the Intel/WAVLINK website.(It is recommended to download the driver first and then install the network card.)
3. Requires a WiFi 6E router and the PC must be on Windows 11 version to enable the 6GHz band.
4. Recommended to use a wifi6 or wifi6e compatible router for faster wireless speed and better network performance.
5. This Wi-Fi card will not boost the speed of the original router, which only helps your computer to receive a better signal and
speed of the router(Increase the maximum wireless bandwidth limit).
6. It has nothing to do with the quality of this adapter when you can't get the maximum speed. The network environment,
router, barriers, laptop and PC 's internal memory…the interference of many factors may affect the speed.

WiFi 7 BE8800Mbps-Intel BE200 Chips-BT5.4

WAVLINK Wi-Fi 7 BE8800 PCIe Tri-band WiFi Card--Innovative Wireless Connectivity!
WAVLINK's triple-band M.2 module, the BE8800 wireless adapter for laptops, features an NGFF/M.2 connector and MLO technology
for minimized signal interference and transmission delays, ensuring a faster, more reliable wireless networking experience.
This module supports MU-MIMO technology, enhancing wireless signals in collaboration with an MU-MIMO compatible router.
Compliant with the 802.11be specification, it operates across 2.4GHz, 5GHz, and 6GHz bands, achieving a maximum data transfer rate of 8800Mbps.

Latest Bluetooth 5.4
Solve the problem of a poor signal by achieving 2x quicker speeds and 4x greater coverage than BT4.0. Coordinate your
game controllers, headphones, and keyboards with the latest Bluetooth standard.

Compatible OS
Support Windows 10/11 64-bit
*Please note that to utilize 6GHz band, the user must be on Windows 11 version.

WPA3 Security
The latest WiFi security protocol, WPA3, brings new capabilities to improve cyber security. More secure encryption in WiFi
password safety and enhanced protection against brute-force attacks combine to safeguard your home network.

Powerful BE200 Chip
The BE200 incorporates the latest IEEE Wi-Fi specification of 802.11BE, introducing the new band extension for Wi-Fi: UHB (Ultra High Band).

Driver Required
Please visit the WAVLINK official website to download and install the driver, enabling you to experience high-speed internet connectivity.

Steps to Install the Wi-Fi Module
1. Unplug the power, open the back cover of the laptop.
2. Find the wireless network card slot and remove the old network card.
3. Install the BE200 module, tighten the screw, fix the antenna and cover the back case.

Specification
Product Model: WN685BE3M-A(chipset: Intel BE200)
Transmission Rate: 2.4GHz: 574Mbps, 5GHz: 2400Mbps, 6GHz: 5800Mbps
Protocol Standard: support IEEE 802.11a/b/g/n/ac/ax/be
Frequency Band: 2.4GHz, 5GHz, 6GHz
Technical Support: MU-MIMO,OFDMA, BSS Coloring, 320MHz, 4096QAM, Target Wake Time(TWT),
Multi Link Operation(MLO), Multi-RU, Enhanced Multi-Link Single Radio(eMLSR)
Support System: Win 11/10 (64 bit)
Bluetooth Version: Bluetooth 5.4
Interface: Compatible with NGFF M.2 E Key Slot
Wireless Security: WPA3/WPA2 encryption

Package Contents
-1x WiFi 7 BE8800 M.2 Module
-1x Screwdriver
-1x Screw
-1x User Manual

Warm Tips
1. This Wi-Fi card will not boost the speed of the original router, which only helps your computer receive a better signal
and speed of the router(Increase the maximum wireless bandwidth limit).
2. It has nothing to do with the quality of this adapter when you can't get the maximum speed. The network environment,
router, barriers, laptop and PC 's internal memory…the interference of many factors can affect the speed.
3. Please note that to utilize 6GHz band, the PC must be on Windows 11 version.
