1PC POWERLD GZM-U60S12 AC90-264V 1.5A 50/60HZ switching power supply Model: GZM-U60S12 Input: AC 90-264V Output: DC 12V/5A Size: 160*98*40mm Features # Low cost and high reliability. # 100% of the product is fully loaded with aging test. # With the corresponding electrical protection function. # Continuous long-term output short-circuit protection. # No minimum load requirement. # High efficiency and low working environment. Product specifications INPUT---- VOLTAGE/CURRENT: 90VAC~265VAC/Imax: 1.5A FREQUENCY: 47 ~ 63Hz EFFICIENCY: >75% typ INRUSH CURRENT: <35A LEAKAGE CURRENT: <0.5mA/220VAC OUTPUT--- Voltage (V): CH1 +12V Current (A): 0.0A to 5.0A LINE REGULATION: <±1.0% LOAD REGULATION: <±1.0% RIPPLE (mVP-P): 0 to 20 MHz <120 TEMPERATURE COEFFICIENT: <±0.1%/°C OUTPUT VOLTAGE ADJ.: 11.5V to 13.0V START-UP TIME: <2.0S (ACIN220V, Io=100%) HOLD-UP TIME:>20mS (ACIN220V, Io=100%) POWER: 60W typ PROTECTION: FUNCTION--- O.C.P.: 6.0A to 8.0A of output Pulsing mode O.V.P.: <16V of output, shut down ISOLATION--- INPUT—OUTPUT: 1.5KVAC/min, Cutoff current<5mA INPUT—FG: 1.5KVAC/min, Cutoff current<5mA OUTPUT—FG: 0.5KVAC/min, Cutoff current<5mA ISOLATION RESISTANCE---- INPUT—OUTPUT: ≥50MΩ, 500VDC INPUT—FG: ≥50MΩ, 500VDC OUTPUT—FG: ≥50MΩ, 500VDC DIMENSIONS---- LENGTH×WIDTH×HEIGHT(mm): 160*98*40mm ENVIRONMENT---- OPERATING TEMPERATURE: 0°C～45°C, 20%～90% RH STORAGE TEMPERATURE: -25 ° C ~ 85 ° C, 10% ~ 95% RH
