Manufacturer: APC / Dell
Model: APC Dell Smart-UPS 3000VA 2700W USB & Serial RM 2U 208V
Condition: New Batteries, Refurbished UPS
Part Number: DLA3000RMT2U
Maximum Output: 2700W / 3000VA
Typical Backup Time at Half Load: 11.5 Minutes (1350 Watts)
Typical Backup Time at Full Load: 3 Minutes (2700 Watts)
Input: NEMA L6-20P, 208V
Output: (1) NEMA L6-20R, (1) NEMA L6-30R
Topology: Line-Interactive
Output Waveform: Sine Wave
Display: LED Status Display with Load & Battery Bar Graphs
Management: Serial Communication, SmartSlot & EPO
Warranty: 1 Year Full Replacement Warranty
APC Dell Smart-UPS 3000VA 2700W USB & Serial RM 2U DLA3000RMT2U - User Manual
DLA3000RMT2U - APC Dell Smart-UPS / DellProduct SeriesSmart-UPSModel / Part NumberDLA3000RMT2UProduct TypeUninterruptible Power Supply (UPS)Power Capacity3000VA / 2700WUPS TopologyLine-InteractiveMain Input Voltage208V ACMain Output Voltage208V ACOutput WaveformSine WaveForm FactorRackmountRack Height2UColorBlackProduct StatusDiscontinued Input Nominal Input Voltage208V ACInput Voltage Range141–255V ACAdjustable Input Voltage Range131–268V ACInput Frequency50/60 Hz ±5 Hz, Auto-Sensing
Input Connection Type
NEMA L6-20P
Input Cord Length8 ft (2.4 m)Number of Input Cables1 Output Output Capacity3000VAOutput Power2700WMaximum Configurable Power3000VA / 2700WNominal Output Voltage208V AC
Output Connection Type
(1) NEMA L6-20R
(1) NEMA L6-30R
Output WaveformSine WaveHarmonic DistortionLess than 5% at Full LoadOutput Frequency - 50Hz47–53 Hz, Synchronized to MainsOutput Frequency - 60Hz57–63 Hz, Synchronized to MainsTransfer Time2 ms Typical Voltage Regulation & Power Protection Automatic Voltage RegulationLine-Interactive Voltage RegulationPower ConditioningContinuous Regulation and Filtering of Utility PowerNoise FilteringFull-Time Multi-Pole Noise FilteringIEEE Surge Let-Through0.3%Clamping Response TimeZeroSurge StandardMeets UL 1449 Batteries & Runtime Battery TypeLead-Acid BatteryReplacement Battery CartridgeRBC43RBC Quantity1Typical Runtime at Half Load11.5 Minutes (1350W)Typical Runtime at Full Load3 Minutes (2700W)Typical Recharge Time3 HoursBattery Life Expectancy3–5 YearsBattery Capacity528 VAh RuntimeBattery Charging Power175W RatedExtended RuntimeNo Communications & Management Local ManagementRS-232 Serial CommunicationSerial InterfaceSmart-UPS Signaling RS-232Management Expansion Slot(1) SmartSlot AvailableNetwork ManagementOptional via APC UPS Network Management CardCompatible NMC3 CardsAP9640, AP9641Compatible NMC2 CardsAP9630, AP9631Legacy Compatible NMC1 CardsAP9617, AP9618, AP9619Web / SNMP ManagementSupported with compatible Network Management CardRemote UPS Monitoring & ManagementSupported with compatible Network Management CardSecure Network ManagementHTTPS, SSH and SNMPv3 supported with compatible newer-generation NMCEnvironmental MonitoringSupported when using a compatible environmental-monitoring Network Management Card such as AP9631 or AP9641PowerChute Network ShutdownSupported with compatible Network Management CardEmergency Power OffEPOUSB CompatibilityNo User Interface, Alerts & Controls Control PanelLED Status Display with Load and Battery Bar GraphsLED Status MonitoringOn Line, On Battery, Replace Battery, Overload and BypassLoad MonitoringLED Load Bar GraphBattery MonitoringLED Battery Charge Bar GraphAudible AlarmsOn-Battery Alarm and Distinctive Low-Battery AlarmAlarm ConfigurationConfigurable Alarm DelaysEmergency Power Off ControlEPO Interface Surge Protection & Filtering Surge Energy Rating480 JNoise FilteringFull-Time Multi-Pole Noise FilteringIEEE Surge Let-Through0.3%Clamping Response TimeZeroSurge Protection StandardUL 1449 Physical Form FactorRackmountRack Height2UHeight3.50 in (8.9 cm)Width19.02 in (48.3 cm)Depth26.0 in (66 cm)Dimensions (H × W × D)3.50 × 19.02 × 26.0 inNet Weight96.21 lb (43.64 kg)ColorBlackMounting ModeRack-MountedMounting LocationFrontMounting PreferenceNo PreferenceTwo-Post MountableNo Environmental Operating Temperature32°F to 104°F (0°C to 40°C)Storage Temperature5°F to 113°F (-15°C to 45°C)Operating Relative Humidity0–95%Storage Relative Humidity0–95%Operating Altitude0–10,000 ftStorage Altitude0–50,000 ft (0–15,240 m)Acoustic Level53 dBAHeat Dissipation400 BTU/hr General Number of Power Module Filled Slots0Number of Power Module Free Slots0RedundantNoProduct / Component TypeUninterruptible Power Supply (UPS) Conformance Product CertificationCSAEU RoHS DirectiveCompliant by ExemptionEnergy Efficiency ClassificationEnergy Efficient ProductTake-Back ProgramYes Condition & Warranty ConditionRefurbished UPS with New BatteriesWarranty1 Year Full Replacement Warranty
