CPU

Supports Intel® Socket 1151 9th/8th Generation Intel® Core™, Pentium® Gold and Celeron® Processors

Supports Intel® 14 nm processors

Supports Intel® Turbo Boost 2.0 Technology

Chipset

Support for Intel® B365

RAM

Intel® B365 Chip

4 x DIMM, supports up to 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered memory

Supports dual-channel memory architecture

Supports Intel® Extreme Memory Profile (XMP) technology

* The maximum supported memory frequency depends on the processor.

** DDR4 2666MHz and higher memory modules will run at up to 2666MHz on 8th Gen Intel® Six-Core or higher processors.

Graphical display

Integrated Graphics - Supports Intel® HD Integrated Graphics

Support Multi-VGA output: HDMI/DVI-D/DisplayPort interface

- HDMI Support: Display resolution up to 4096 x 2160 @ 30 Hz

- Supports DVI-D output: Display resolution up to 1920 x 1200 @ 60 Hz

- Supports DisplayPort 1.2: Display resolution up to 4096 x 2304 @ 60 Hz

Shared video memory up to: 1024 MB

Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™

Supports up to 3 independent monitors

Multiple Graphic Display Technology

Supports AMD CrossFireX™ Technology

Expansion slot

1 x PCIe 3.0 x16 (x16 mode)

1 x PCIe 3.0 x16 (max x4 mode)

1 x PCIe 3.0/2.0 x1 expansion card slot

Storage function(subject to shipment)

Intel® B365 Chip :

1 x M.2 Socket 3 slot, support M key, 2242/2260/2280 type storage device (SATA & PCIE 3.0 x 4 mode)

1 x M.2 Socket 3 slot, support M key, 2242/2260/2280 type storage device (PCIE 3.0 x 4 mode)

6 x SATA 6Gb/s connectors, grey

Support Raid 0, 1, 5, 10

Intel® Optane™ Memory Technology

Internet function

Intel® I219V, 1 x Gigabit LAN

TUF LANGuard Network Security Protection

Sound effect

Realtek® ALC1200 8-Channel High Definition Audio Codec

- Support: Audio interface detection (Jack-detection), custom front panel audio jack function

Audio function:

- Audio shielding technology: high-precision analog/digital separation does not interfere with each other

- Channel layered isolation design: left and right channel layered wiring to bring better audio signal quality

- High Quality Japanese Audio Capacitor: Let you enjoy clear and high fidelity sound.

* It needs to cooperate with the HD Audio module on the front panel of the chassis to support 8-channel audio output.

USB

Intel® B365 Chip :

6 x USB 3.1 Gen 1 connection ports (4 @rear, blue, 2 @front)

Intel® B365 Chip :

6 x USB 2.0/1.1 ports (2 @rear, 4 @front)

Backplane I/O Connectors

1 x PS/2 mouse and keyboard interface

1 x DVI-D port

1 x DisplayPort interface

1 x HDMI port

1 x LAN (RJ45) port

4 x USB 3.1 Gen 1 Type-A up to 5Gbps

2 x USB 2.0 ports

1 x 8 channel audio interface

Internal I/O Interface

1 x USB 3.1 Gen 1 port to expand 2 external USB 3.1 Gen 1 ports (19-pin, moss green)

2 x USB 2.0 ports can be extended to 4 external USB 2.0 ports

1 x Programmable RGB header

2 x M.2 Socket 3 slots, support M key, 2242/2260/2280 type storage device

1 x Serial Connection Socket (COM)

1 x Aura RGB strip header

6 x SATA 6Gb/s device connection sockets

1 x CPU fan power socket

2 x Chassis Fan Connectors

1 x S/PDIF_Out digital audio connector header

1 x 24-pin EATX motherboard power socket

1 x 8-pin EATX 12V power connector

1 x Front Panel Audio Interface (AAFP)

1 x Clear CMOS Jumper

1 x System Panel Connector

BIOS

128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multilingual BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 Favorites, History, F6 Qfan Control, F12 Screenshot, and ASUS DRAM SPD (Serial

Presence Detect) memory information

O S

Windows® 10 64-bit

Dimensions

mATX version structure

9.6" x 9.5" (24.4cm x 24.1cm)
