Aten VS92A VGA Switchbox - 1 x Computer Aten VS92A VGA Switchbox - 1 x Computer

International Customers: All electronic products are packaged for sale in the US with US voltage.

Package Contents: 1 x VS-92A 1 x DC 9V Power Adapter 1 x User Manual

Additional Information: Transmission distance of up to 210 feet Daisy-Chain multiple units together for even more outputs Ideal for public broadcasting; remote monitoring; classroom and training facilities

Product Description

This item is brand-new, factory sealed.

The Video Separator is a signal booster and splitter that is used to
take video input from a single source and direct it to two video
outputs for monitors using analog signals. The signal boost
obtained by using the VS92A allows you to not only split the signal
but to extend the distance so that you can send the signal to about
210 feet. (Your average VGA card, combined with a standard VGA
cable, can send a clear VGA signal approximately 25 feet.) This
makes public broadcasts from a single computer very feasible. If
you want to display the same information on many monitors at once,
such as in a classroom environment, or at a demonstration, this
product performs incredibly well.
Bandwidth is the term that is used to describe the signal capacity
of these units. In general, bandwidth is directly proportional to
the amount of data transmitted per unit of time. Specifically, in
analog signals, bandwidth is the difference between the highest-
frequency and the lowest frequency components of a givin signal.
For example a voice telephone signal has a bandwidth of 3000 Hz (or
3000 cycles per second), where an analog TV signal has a bandwidth
of approximately 6MHz (or 6 million cycles per second) which is
approximately 2000 times greater than a simple voice phone call.
These units have a bandwidth of 250MHz (which is 250 million cycles
per second) and that over 40 times greater than a simple TV signal.
This huge bandwidth allows for the transmission of large amounts of
information at a very high rate of speed, and thus you can use the
very high resolution setting of 1920 x 1440 in 24 or 32 bit true
color mode.
* One video input with two video outputs
* High 250 MHz video bandwidth
* Transmission distance of up to 210 feet
* Suitable for SVGA, VGA, and Multisync monitors
* Daisy-Chain multiple units together for even more outputs
* Ideal for public broadcasting; remote monitoring; classroom and training
facilities. -- SPECIFICATIONs - Input : (1) 15 pin HDB Male
Output: (2) 15 pin HDB Female
INDICATORs - LED for Power
BANDWIDTH - VGA: 250 MHz
RESOLUTION - 1920 x 1440 @ 60 Hz
SIGNAL TYPE- VGA; SVGA; MultiSync
DISTANCE - 210 ft. max.
POWER- DC 9V 180mA (Max)
SIZE - 2.95"w x 0.79"h x 5.12"d WT.- 15.75 ounces
Package Contents:

1 x VS-92A

1 x DC 9V Power Adapter

1 x User Manual

SpecificationPower DescriptionInput Voltage9 V DCPower Consumption820 mWPhysical CharacteristicsWeight (Approximate)11.20 ozProduct Warranty InformationIN NO EVENT SHALL THE DIRECT VENDOR LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or update. For further inquiries, please contact your direct vendor.VideoMaximum Video Resolution1920 x 1440Graphics Modes
