Barco Coronis Fusion 6MP MDCC-6530 MKII IPS 30" Radiology Monitor - Year all-state warranty valid from date of purchase

Factory warranty valid until overall condition with little signs of use. There are some scuffs on the base of the monitor stand (see photos). Otherwise, the monitor is in excellent physical condition.

There is a small bright spot on the display that is visible primarily when viewing lighter-colored backgrounds. The bright spot measures approximately 0.5" x 0.5" and is circled in red in the photos for reference.

The bright spot becomes significantly less noticeable when viewing darker colors and is not visible against a black background. Please review all photos carefully for the exact appearance and location of the bright spot before purchasing.

Item has been fully tested and is guaranteed to work.

Original packaging and accessories included.

What's Included:

• Coronis Fusion 6MP display
• Cables for Mains, Video and shipping via FedEx Ground or UPS Ground.
• 1-business day handling time.
• Please note we cannot ship to freight forwarders, international exporters, or 3rd-party eTail logistics hubs.
• Signature will be required, no exceptions can be accepted within 30 days if the item is returned in its original condition.
• 20% restocking fee applies if the item shows signs of use or the packaging has been opened.

Detailed Specifications:

General specificationsScreen technologyIPSActive screen size (diagonal)772 mm (30.4")Active screen size (H x V)654 x 409 mm (25.8 x 16.1")Aspect ratio (H:V)16:10ResolutionNative 6MP (3280 x 2048 pixels)
Configurable to 2 x 3MP+ (1640 x 2048 pixels)
Configurable to 2 x 3MP (1536 x 2048 pixels)Pixel pitch0.1995 mmColor imagingYesGray imagingYesBit depth30 bitViewing angle (H, V)178°Uniformity correctionColor PPUSteadyColorYes, when used as system with Barco Display Controller and with QAWeb Enterprise 2.2 or later.Ambient light presetsYes, reading room selectionAmbient light sensorYesFront sensorYes, I-GuardMaximum luminance (panel typical)1050 cd/m²DICOM calibrated luminance600 cd/m²Contrast ratio (panel typical)2000:1Response time ((Tr + Tf)/2) (typical)18 msHousing colorBlack / WhiteVideo input signals2x DisplayPort 1.2Video output signals1x DisplayPort (MST)USB ports1x USB 2.0 upstream (endpoint)
2x USB 2.0 downstream
1x USB 2.0 downstream with high-power charging functionalityPower rating100-240 Vac, 50/60 Hz, 3.6-1.6 APower consumption80 W (nominal) @ calibrated luminance of 600 cd/m²
< 0.5 W (hibernate)
< 0.5 W (standby)Dimensions with stand (W x H x D)714 x 524~624 x 240 mmDimensions w/o stand (W x H x D)714 x 478 x 74 mmDimensions packaged (W x H x D)800 x 650 x 295 mmNet weight with standMDCC-6530:17.7 kg
MDCC-6530 NC: 16.3 kgNet weight w/o standMDCC-6530: 13.1 kg
MDCC-6530 NC: 11.7 kgNet weight packagedMDCC-6530: 22.3 kg (without optional accessories)
MDCC-6530 NC: 20.9 kg (without optional accessories)Tilt-5° to +25°Swivel-30° to +30°PivotN/AHeight adjustment range100 mmMounting standardVESA (100 mm)Screen protectionMDCC-6530: Protective, anti-reflective glass cover
MDCC-6530 NC: No glass coverRecommended modalitiesAll digital images, except digital mammographyCertificationsFDA 510(k) K191845
CE0123 (Medical Device)
CCC (China)
INMETRO (Brazil - Prodcut numbers K9301636B(1X), K9301638B(1X)
KC (Korea)
BIS (India)
EAC (Russia, Kazakhstan, Belarus, Armenia and Kyrgyzstan)
Safety specific:
IEC 60950-1:2005 + A1:2009+A2:2013
EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013
IEC 62368-1:2018
EN IEC 62368-1:2020 + A11:2020
IEC 60601-1:2005+A1:2012+A2:2020
EN 60601-1:2006 + A1:2013 + A12:2014+A2:2021
AAMI ES 60601-1:2005 + A1:2012+A2:2021
CAN/CSA C22.2 No. 60601-1:2014 (Reaffirmed 2022)

EMI specific:
IEC 60601-1-2:2014+A1:2020 (ed.4.1)
EN 60601-1-2:2015+A1:2021 (ed.4.1)
FCC part 15 Class B
ICES-001 Level B
VCCI (Japan)

Environmental:
EU RoHS
China RoHS
REACH
Canada Health
WEEE
Packaging DirectiveSupplied accessoriesVideo cables
Mains cables
USB cableOptional accessoriesGraphics board
Touch padQA softwareQAWebOperating temperature0 °C to 35 °C (10 °C to 30 °C within specs)Storage temperature-20 °C to 60 °COperating humidity20% to 85% (non-condensing)Storage humidity20% to 85% (non-condensing)Operating pressure70 kPa minimumStorage pressure50 to 106 kPa
