Item Description:

CIENA 160-9401-900 QSFP28 100GBASE-LR4 4X25G WDM SMF 1310NM LC TRANSCEIVER

The160-9401-900is amanufacturer part number for aCiena 100GBASE-LR4 QSFP28 optical transceiver module. It is a hot-pluggable network component designed for high-speed fiber-optic data transmission over relatively long distances, typically used to connect data centers or aggregate core network links

Are you looking tobuy replacement transceivers, or do you need a Ciena 6500 shelf as well?

Core Specifications

• The primary technical details for this specific module include:
  • Form Factor:QSFP28 (Quad Small Form-factor Pluggable 28)
  • Data Rate:100 Gbps (specifically 103.125 Gbps for 100G Ethernet client traffic)
  • Reach:Up to10 kilometers (km)
  • Media Type:Single-Mode Fiber (SMF)
  • Connector Type:Duplex LC
  • Wavelength:Uses a 4-channel LAN WDM multiplexing scheme across the 1310nm band (specifically spanning 1295.56nm to 1309.14nm).
  • Monitoring:Includes Digital Optical Monitoring (DOM / DDM) to track real-time operating parameters like TX/RX power, temperature, and voltage


Platform Compatibility & Network UsageThis part number natively targets specificCiena hardwareand operating systems:

• Supported Platforms:It is officially used on theCiena 6500 Packet-Optical Platform(on applicable 100G client line cards) and the Ciena Waveserver Ai platforms.
• Application Constraints:The 160-9401-900 is engineeredstrictly for 100G Ethernet client traffic. It does not support OTU4 (Optical Transport Network) or 128G Fibre Channel protocols.
• 160-9401-900 vs. 160-9402-900:If you need a multi-rate module that supports OTU4 or Fibre Channel on your Ciena line cards, you must use the companion160-9402-900SKU instead. They are not interchangeable in Ciena's ecosystem

Condition:

This item is sold in USED WORKING PULLED FROM NETWORK condition.

UNIT MAY EXIBIT SLIGHT SCRATCHES DINGS OR DENTS DUE TO NORMAL USAGE

Warranty Information:

All equipment ships with a60-day warrantyunless specified otherwise. Physical damage must be disclosed within 7 days of receipt to qualify for a full refund.

Shipping:

>>>>WE SHIP WORLDWIDE, Message us for rates, WE Can ship on your DHL, FEDEX, or UPS Account.<<<<

Shipping is calculated based on location unless specified otherwise.

Payment:

Payments must be made within 48 hours to guarantee item is won and an unpaid item case is not opened.

We can ship on your FEDEX, UPS, DHL account if you prefer. Let us know at check out. Thank you
