Specification Description

Maximum input power

3W

Connector

TNC male

VSWR1

2.5:1 or less

Characteristic impedance

50 ohm

Antenna base and radome color

Cisco Raven Black

Antenna dimensions

9 (L) x 1.2 (W) x 7/16 in (D)
(229 x 30.5 x 11 mm)

Operating temperature

-22° to 158°F (-30° to 70°C)

Operating frequency ranges

•698-806 MHz

•824-894 MHz

•925-960 MHz

•1710-1885 MHz

•1920-1980 MHz

•2110-2170 MHz

•2500-2690 MHz

Maximum Peak Gain

2 dBi

1

0 degree position

5

TNC connector

2

45 degree position

6

Green band

3

90 degree position

7

Product ID

4

Articulating joint
