N/A
IOS 15.2
ipbase
2x C3KX-PWR-350WAC (Takes C13 Plug)
Minor signs of prior use, including
scratches, scuffs and possible adhesive
residue remaining.
These signs appear mainly on the top of the unit
and the units face plate. See Photos for more cosmetic details about the
unit. Power Cord(s)
C13 Plug Needed
Switch#show diagnostic result switch 1Switch 1: SerialNo : FCW2019B6XM Overall Diagnostic Result for Switch 1 : PASS Test results: (. = Pass, F = Fail, U = Untested) 1) TestPortAsicStackPortLoopback ---> .
2) TestPortAsicLoopback ------------> .
3) TestPortAsicRingLoopback --------> .
4) TestPortAsicCam -----------------> .
5) TestMicRingLoopback -------------> .
6) TestPortAsicMem -----------------> .
7) TestInlinePwrCtlr ---------------> .
Switch#show env all
FAN 1 is OK
FAN 2 is OK
FAN PS-1 is OK
FAN PS-2 is OK
SYSTEM TEMPERATURE is OK
System Temperature Value: 26 Degree Celsius
System Temperature State: GREEN
Yellow Threshold : 46 Degree Celsius
Red Threshold : 60 Degree Celsius
SW PID Serial# Status Sys Pwr PoE Pwr Watts
-- ------------------ ---------- --------------- ------- ------- -----
1A C3KX-PWR-350WAC AZS161701A6 OK Good Good 350/0
1B C3KX-PWR-350WAC LIT17130M3K OK Good Good 350/0SW Status RPS Name RPS Serial# RPS Port#
-- ------------- ---------------- ----------- ---------
1 Not Present <>
Switch#show inv
NAME: "1", DESCR: "WS-C3750X-24"
PID: WS-C3750X-24T-S , VID: V01 , SN: FDO1424P0S4NAME: "Switch 1 - Power Supply 0", DESCR: "FRU Power Supply"
PID: C3KX-PWR-350WAC , VID: V02A , SN: AZS161701A6NAME: "Switch 1 - Power Supply 1", DESCR: "FRU Power Supply"
PID: C3KX-PWR-350WAC , VID: V02L , SN: LIT17130M3KNAME: "Switch 1 - FRULink Slot 1 - FRULink Module", DESCR: "FRULink 10G ST Module"
PID: C3KX-NM-10G , VID: V01 , SN: FDO14300W0K
Switch#show post
Stored system POST messages:Switch 1
---------POST: CPU MIC register Tests : Begin
POST: CPU MIC register Tests : End, Status PassedPOST: MA BIST : Begin
POST: MA BIST : End, Status PassedPOST: TCAM BIST : Begin
POST: TCAM BIST : End, Status PassedPOST: SF ASIC BIST : Begin
POST: SF ASIC BIST : End, Status PassedPOST: Switch Fabric Memory Tests : Begin
POST: Switch Fabric Memory Tests : End, Status PassedPOST: CPU MIC interface Loopback Tests : Begin
POST: CPU MIC interface Loopback Tests : End, Status PassedPOST: PortASIC RingLoopback Tests : Begin
POST: PortASIC RingLoopback Tests : End, Status PassedPOST: Thermal, Fan Tests : Begin
POST: Thermal, Fan Tests : End, Status PassedPOST: PortASIC Port Loopback Tests : Begin
POST: PortASIC Port Loopback Tests : End, Status PassedPOST: PortASIC Macsec Loopback Tests : Begin
POST: PortASIC Macsec Loopback Tests : End, Status PassedPOST: EMAC Loopback Tests : Begin
POST: EMAC Loopback Tests : End, Status PassedSwitch#show int statusPort Name Status Vlan Duplex Speed Type
Gi1/0/1 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/2 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/3 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/4 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/5 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/6 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/7 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/8 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/9 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/10 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/11 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/12 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/13 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/14 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/15 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/16 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/17 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/18 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/19 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/20 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/21 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/22 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/0/23 notconnect 1 auto auto 10/100/1000BaseTXPort Name Status Vlan Duplex Speed Type
Gi1/0/24 notconnect 1 auto auto 10/100/1000BaseTX
Gi1/1/1 notconnect 1 auto auto Not Present
Gi1/1/2 notconnect 1 auto auto Not Present
Gi1/1/3 notconnect 1 auto auto Not Present
Gi1/1/4 notconnect 1 auto auto Not Present
Te1/1/1 notconnect 1 full 10G Not Present
Te1/1/2 notconnect 1 full 10G Not Present
Fa0 disabled routed auto auto 10/100BaseTX
Switch#show pow iModule Available Used Remaining
(Watts) (Watts) (Watts)
------ --------- -------- ---------
1 n/a n/a n/a
Interface Admin Oper Power Device Class Max
(Watts)
--------- ------ ---------- ------- ------------------- ----- ----Switch#show license
Index 1 Feature: ipservices
Period left: 8 weeks 4 days
License Type: Evaluation
License State: Active, Not in Use, EULA not accepted
License Priority: None
License Count: Non-CountedIndex 2 Feature: ipbase
Period left: Life time
License Type: Permanent
License State: Active, In Use
License Priority: Medium
License Count: Non-CountedIndex 3 Feature: lanbase
Period left: 0 minute 0 secondSwitch#show ver
Cisco IOS Software, C3750E Software (C3750E-UNIVERSALK9-M), Version 15.2(1)E2, RELEASE SOFTWARE (fc1)
Technical Support: (c) 1986-2014 by Cisco Systems, Inc.
Compiled Thu 13-Mar-14 03:26 by prod_rel_teamROM: Bootstrap program is C3750E boot loader
BOOTLDR: C3750E Boot Loader (C3750X-HBOOT-M) Version 12.2(53r)SE1, RELEASE SOFTWARE (fc1)Switch uptime is 15 minutes
System returned to ROM by power-on
System restarted at 01:27:30 UTC Wed Mar 30 2011
System image file is reload reason: Unknown reasonThis product contains cryptographic features and is subject to United
States and local country laws governing import, export, transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import, export, distribute or use encryption.
Importers, exporters, distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws, return this product immediately.A summary of U.S. laws governing Cisco cryptographic products may be found you require further assistance please contact us by sending email to
(email)License Level: ipbase
License Type: Permanent
Next reload license Level: ipbasecisco WS-C3750X-24 (PowerPC405) processor (revision A0) with 262144K bytes of memory.
Processor board ID FDO1424P0S4
Last reset from power-on
1 Virtual Ethernet interface
1 FastEthernet interface
28 Gigabit Ethernet interfaces
2 Ten Gigabit Ethernet interfaces
The password-recovery mechanism is enabled.512K bytes of flash-simulated non-volatile configuration memory.
Base ethernet MAC Address : D0:D0:FD:25:56:00
Motherboard assembly number : 73-12530-04
Motherboard serial number : FDO14241601
Model revision number : A0
Motherboard revision number : A0
Model number : WS-C3750X-24T-S
Daughterboard assembly number : 800-32727-01
Daughterboard serial number : FDO14240G5U
System serial number : FDO1424P0S4
Top Assembly Part Number : 800-31327-01
Top Assembly Revision Number : A0
Version ID : V01
CLEI Code Number : COMJV00ARA
Hardware Board Revision Number : 0x02
Switch Ports Model SW Version SW Image
------ ----- ----- ---------- ----------
* 1 30 WS-C3750X-24 15.2(1)E2 C3750E-UNIVERSALK9-M
Configuration register is 0xF
