Printer Type:
• Direct Thermal / Thermal Transfer
Maximum print width:
• 4.10” (104.1mm).
Print Length Range:
•0.25” -99” (6.35 -2514.6mm)
Print Speed:
• 12ips (304mm/s)
Print Resolution:
• 203 dpi.
Memory:
• 32MB /64MB
Dimensions:
• 12.62” W x 12.7” H x 18.6” D (320.5mm x 322.6mm x 472.4mm)
Weight:
• 20.5Kg
Operating Temperature:
• 0°C to 40°C
Power Source:
• Auto-sensing 90-132 or 180-264 VAC @47-63Hz
Construction:
• Metal cabinet, clear side window to easily monitor media supply levels
Communication Ports:
• Standard: Serial RS232, USB2.0, Parallel Bi-Directional.
• Optional: 10/100 BaseT Ethernet, 2 USB Host, W-LAN, 802.11 a/b/g , SDIO, GPIO
Software (not included)
• NETira CT - Complete printer set up utility
• NETira LD - Label design software
• Embedded Network web pages
• Windows Drivers - NT, XP, Vista
Barcodes:
• Linear: Code 3 of 9, UPC-A, UPC-E, Interleaved 2 of 5, Industrial 2 of 5, Std 2 of 5, Code 11, Code 93, Code 128, EAN-8, EAN-13, HIBC, Codabar, Plessey, UPC 2 and 5 digit addendums, Postnet, UCC/EAN Code 128, Telepen, Planetcode, FIM, USPS-4 State
• 2D Symbologies: MaxiCode, PDF417, USD-8, Datamatrix, QR Code, Codeablock, Code 16k, Aztec, TLC 39, Micro PDF417, GS1 Databar
Resident fonts:
• Ten alphanumeric fonts from 2.5 to 23 point size, including OCR-A, OCR-B, CG Triumvirate ™ smooth font from AGFA®
• Scalable Fonts: CG Triumvirate Bold Condensed, CG Triumvirate & CG Times with Cyrillic, Greek Arabic and Hebrew character support.
Downloadable font types:
• True-Type, Bitmap
Character set:
• Over 50 resident character sets; Unicode/UTF8 support.
Font expansion/rotation:
• All fonts expandable vertically and horizontally up to 24x; fonts and graphics can be printed in four directions: 0°, 90°, 180° and 270°s.
Graphics supported:
• PCX,.BMP and .IMG files
Reversible field/mirror image:
• Any font or graphic field can be printed as a normal or reverse image.
