Monitor Thickness
1.12" / 28.45 mm panel depth
Aspect Ratio
16:10
Active Area
8.54" x 5.34" / 216.96 mm x 135.6 mm
Resolution
1280 x 800
Other Supported Resolutions
640 x 480 @ 60Hz
800 x 600 @ 60Hz
1024 x 768 @ 60Hz
1280 x 800 @ 60Hz
1920 x 1080 @ 60Hz
1920 x 1200 @ 60Hz
Viewing Angle
Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total
Number of Colors
262,000
Brightness (typical)
LCD panel: 350 nits
PCAP + DC Power: 315 nits
PCAP + USB-C 5V power: 200 nits
Response Time-total (typical)
29 msec
Contrast Ratio
800:1
Touch Interface
USB
Surface Treatment
Anti-glare
On Screen Display
Accessible through switches along the bottom:
Controls: Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Video Priority, Information, Touch on Sleep Mode, Peripheral Port
Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese
Lockouts: OSD, Power
I/O Ports
1 x USB Type-C
1 x Audio jack (Line-in)
1 x VGA (Micro-HDMI female connecter)
1 x HDMI
1 x 12V D/C input
3 x Micro-USB ports (Top, Left, Right) to support Elo Edge Connect peripherals
Speakers
2 x 2W internal speakers
Video
Analog VGA
HDMI
USB Type-C (support DP Alt mode)
Suggest using Elo USB Type-C to Type-C (Elo P/N: E710364) cable to prevent any compatibility issues
Input Video Frequency
Horizontal: 31.5 - 80 KHz
Vertical: 60 Hz
Power Consumption (Typical)
Monitor + AC/DC adapter
ON: 7.43 W
SLEEP: 1.26 W
OFF: 0.2 W
Monitor Dimensions (without Stand)
10.03" x 6.99" x 1.14" / 254.80 mm x 177.50 mm x 29.00 mm
Operating Temperature
0°C to 40°C / 32°F to 104°F
Storage Temperature
-20°C to 60°C / -4°F to 140°F
Humidity
Operating: 20% to 80%; Storage: 10% to 95% (38.7℃ max wet bulb temperature)
MTBF
50,000 hours demonstrated
Mounting Options
VESA 4-hole 75mm mounting interface on rear of unit
