Elo E700813 1515L 15" Touchscreen Monitor with Stand 1024 x 768 800:1 BlackThe box is damaged, but the monitor is not damaged. The Elo 1515L 15-inch standard format touchscreen monitor delivers professional-grade built for touch reliability in an affordable compact footprint. The space-saving touchscreen includes a stable base, side controls and lock-out capability for public use. Whether used as a desktop or a wall-mounted unit, the 1515L offers flexibility for mounting and two touch technology options. - Economical and reliable
- Energy-saving LED backlights
- Up to 1024 x 768 resolution at 75 Hz
- Touchscreen sealed against dirt, dust and liquids
- Dual serial/USB interface
- Removable stand and VESA mounting option
- Mounting holes on stand bottom for tabletop security
- Digital on-screen display (OSD)
- Both Internal power and optional external 12VDC power supply
- Worldwide agency approvals
- Part Number(s): IntelliTouch (Worldwide) - E700813, IntelliTouch (EMEA) - E399324, AccuTouch (Worldwide) - E210772, AccuTouch (EMEA) - E344320
- Enclosure Color: Dark Gray
- Touch Technology & Capacity: 5-Wire Resistive (AccuTouch) - Single-Touch, SAW (IntelliTouch Surface Acoustic Wave) - Single Touch
- Diagonal Size: 15'' diagonal, Active matrix TFT LCD (LED)
- Aspect Ratio: 4:3
- Active Area: 12.0" x 9.0" / 304mm x 228mm
- Resolution: 1024 x 768
- Other Supported Resolutions: 640 x 350 70 Hz; 640 x 480 60, 72, 75 Hz; 640 x 480 66 Hz; 720 x 400 at 70 Hz; 800 x 600 at 56, 60, 72 or 75 Hz; 832 x 624 at 75 Hz; 1024 x 768 65 Hz; 1024 x 768 60, 70, 75 Hz
- Viewing Angle: Horizontal: ± 80° or 160° total / Vertical: 70°/80° or 150° total
- Number of Colors: 16.2 million
- Brightness (typical): LCD panel: 250 nits, AccuTouch: 200 nits, IntelliTouch: 225 nits
- Response Time-total (typical): 8 msec
- Contrast Ratio: 800:1
- Input Video Format: Analog VGA on Female DB-15 connector
- Input Video Frequency: Horizontal: 31.5-60.2 kHz / Vertical: 56.3-75 Hz
- Power: Internal AC, power connector-C6 type
- Input voltage range: 100-240VAC, 50/60Hz
- Monitor input power connector: Coaxial power jack (2.0mm pin outer diameter, 6.4mm barrel inner diameter, 8.8mm Barrel depth)
- Monitor input voltage range: 12VDC +/- 5%
- Power Consumption (Typical) AC in, monitor only ON: 9.60 W
- Power Consumption (Typical) AC in, monitor only SLEEP: 1.38 W
- Power Consumption (Typical) AC in, monitor only OFF: 0.30 W
- I/O Ports: VGA, DC jack, AC jack, USB Type B, RS232 (DB-9)
- On Screen Display: Accessible through switches along the bottom; Controls: Menu, Power, Up, Down, Select; Settings: Auto-Adjust, Brightness, Contrast, H-position, V-position, Clock, Phase, Color Temperature, OSD Timeout, OSD Language, Sharpness, Recall Defaults, Information; Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese;
- Lockouts: OSD, Power
- Monitor Dimensions (without Stand): 11.0" x 13.8" x 2.2" / 280 mm x 350 mm x 55 mm
- Monitor Dimensions (with Stand): 12.2" x 13.8" x 6.9" / 310 mm x 350 mm x 175 mm
- Operating Temperature: 0°C to 40°C / 32°F to 104°F
- Storage Temperature: -20°C to 60°C / -4°F to 140°F
- Humidity: Operating: 20% to 80%; Storage: 10% to 95% (38.7° maximum wet bulb temperature)
- MTBF: 50,000 hours demonstrated
- Mounting Options: VESA 4-hole 75mm mounting interface on rear of unit
- Regulatory approvals and declarations: Canada CUL, IC; China CCC, Europe CE, United Kingdom UKCA, Korea KCC, Taiwan BSMI, United States FCC, UL, Japan VCCI, International CB, Australia RCM, Russia EAC, Mexico NoM, RoHS, China RoHS, WEEE, REACH
Condition is brand new.Shipping is FREE for this item. We strive to ship everything out within a day of purchase. Please click on our store link above to view more great items like this.LOCATION:  |
|
