Item description
GIGABYTE Z590I VISION D Motherboard Intel Z590 LGA1200 DDR4 Mini-ITX M.2 Core DP
CPU
LGA1200 socket, supports:
11th Generation Intel® Core™ i9 Processor / Intel® Core™ i7 Processor / Intel® Core™ i5 Processor
10th Generation Intel® Core™ i9 processor / Intel® Core™ i7 processor / Intel® Core™ i5 processor / Intel® Core™ i3 processor / Intel® Pentium® processor / Intel® Celeron® processor*
**With 4 MB Intel® Smart Cache, i.e. Intel® Celeron® G5xx5 series processors.
L3 cache depends on CPU
Chipset
Intel® Z590 Express Chipset
RAM
11th Generation Intel® Core™ i9/i7/i5 Processors:
Supports 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz
10th Generation Intel® Core™ i9/i7 Processors:
Supports DDR4 2933/2666/2400/2133 MHz
10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® Processors:
Supports DDR4 2666/2400/2133 MHz
2 x DDR4 DIMM slots supporting up to 64 GB (single slot supports 32 GB capacity)
Supports dual-channel memory technology
Supports ECC Un-buffered DIMM 1Rx8/2Rx8 memory (operating in non-ECC mode)
Support non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory
Supports Extreme Memory Profile (XMP) memory
Display function
Display based processor + Intel® Thunderbolt™ 4 controller:
2 x Intel® Thunderbolt™ 4 ports (USB Type-C® port), support DP and Thunderbolt™ technology display output, can support up to 5120 x 2880@60 Hz with 24 bpp resolution (single display output)
* Due to the I/O resource limitation of PC architecture, the number of Thunderbolt™ devices that can be connected in series depends on the PCI-E devices installed on the motherboard.
* Support DP 1.4 version and HDCP 2.3.
Sound effect
Integrated Realtek® ALC4080 chip
Support for DTS:X® Ultra
Support High Definition Audio
Support 2 channels
The internet
Integrated Intel® 2.5GbE network chip (2.5 Gbit/1 Gbit/100 Mbit)
Wireless communication module
Intel® Wi-Fi 6 AX200
WIFI a, b, g, n, ac, ax, support 2.4/5 GHz wireless dual-band
BLUETOOTH 5.1
Support 11ax 160MHz wireless communication standard, can support up to 2.4 Gbps
* Actual transfer speed will vary depending on usage environment and equipment.
Expansion slot
1xPCI-E x16 slot, supports x16 running specification
PCI-E x16 slot supports PCI-E 4.0)*
* Only 11th generation processors support this feature.
Storage device interface
CPU based:
1 x M.2 slot (support Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD) (M2A_CPU)*
* Only 11th generation processors support this feature.
Based on chipset:
1xM.2 slot on the back of the motherboard (supports Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD) (M2P_SB)
4xSATA 3.0 ports
Supports RAID 0, RAID 1, RAID 5 and RAID 10 functions
Intel® Optane™ Memory Ready
USB
Based on chipset:
1 x USB Type-C® port, supports USB 3.2 Gen 1, needs to be connected from the USB socket on the motherboard via a cable
2xUSB 3.2 Gen 2 Type-A ports (red) on rear window IO
6xUSB 3.2 Gen 1 ports (4 in the rear window IO, 2 need to be connected from the USB socket in the motherboard via a cable)
Based on Chipset + Intel® Thunderbolt™ 4 Controller:
2xUSB Type-C® ports on rear window IO, support USB 3.2 Gen 2
Based on Chipset + USB 2.0 Hub:
2xUSB 2.0/1.1 ports, which need to be connected from the USB socket in the motherboard via a cable
Internal socket
1x24 PIN motherboard power socket
1 x 8 PIN CPU power socket
1xCPU fan header
3xsystem fan sockets
1xProgrammable LED Strip Power Outlet
1xRGB LED strip power socket
4xSATA 3.0 ports
2xM.2 SSD slots
1xmotherboard jumper socket
1xspeaker socket
1 x USB Type-C® socket, supports USB 3.2 Gen 1
1xUSB 3.2 Gen 1 socket
1xUSB 2.0/1.1 socket
1xclear CMOS data pin
1xcomputer case open detection pin
Rear panel unit connection socket
1xDP input interface
2xThunderbolt™ 4 sockets (USB Type-C® port, supports USB 3.2 Gen 2)
2xUSB 3.2 Gen 2 Type-A ports (red)
4xUSB 3.2 Gen 1 ports
1xQ-Flash Plus button
1xRJ-45 network cable interface
2xSMA antenna ports (2T2R)
2xaudio interfaces
I/O Controller
Integrated iTE® I/O controller chip
BIOS
1 x 256 Mbit flash
Use an authorized AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Operating system
Support Windows 10 64-bit
Form Factor
Mini-ITX ; 17.0cm x 17.0cm
