Category Specification Central Processor (CPU)
CPU Socket LGA1700 socket CPU Support Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors L3 Cache Depends on CPU
(Please refer to the GIGABYTE website for the supported CPU list) Chipset
Chipset Intel® Z790 Express Chipset Memory
Memory Support Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MHz Memory Slots 4x DDR5 DIMM Slots Max. Memory Capacity Up to 192GB (Supports 48GB-capacity DIMMs) Memory Channel Dual Channel ECC Memory Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory (operates in non-ECC mode) Non-ECC Memory Support for Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory XMP Support Support for Extreme Memory Profile (XMP) memory Note (Please refer to the GIGABYTE website for the supported memory modules list.) Onboard Graphics
Graphics Processor Integrated in the CPU - Intel® HD Graphics support Video Outputs 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Supports HDMI 2.0 and HDCP 2.3.
1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Supports DisplayPort 1.2 and HDCP 2.3. Note (Graphics specifications may vary by CPU.) Audio
Audio Chipset Realtek® ALC1220 codec Features * DSD audio support for rear audio output jacks.
* High Definition Audio
* 2/4/5.1/7.1-channel support
* You can reconfigure the audio jack functions in the audio software. To configure 7.1-channel audio, please access the audio software.
* Support for S/PDIF Out Networking
Wired LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) Wireless Communication
Module (Rev 1.0) Intel® Wi-Fi 6E AX211
- IEEE 802.11 a/b/g/n/ac/ax, supports 2.4/5/6 GHz frequency bands
- Bluetooth 5.3
- Supports 11ax 160MHz wireless communication standard Module (Rev 1.1) Realtek® Wi-Fi 7 RTL8852CE
- IEEE 802.11 a/b/g/n/ac/ax, supports 2.4/5/6 GHz frequency bands
- Bluetooth 5.3
- Supports 11ax 160MHz wireless communication standard Note (Actual transmission speed may vary depending on the environment and equipment.) Expansion Slots
From CPU 1x PCIe x16 slot, supporting PCIe 5.0 and x16 operation (PCIEX16)
* For the best graphics performance, install the graphics card in the PCIEX16 slot. From Chipset 1x PCIe x16 slot, supporting PCIe 4.0 and x4 operation (PCIEX4_1) Storage Interface
From CPU 1x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD) (M2A_CPU) From Chipset 1x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD) (M2Q_SB)
1x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD) (M2P_SB)
6x SATA 3.0 connectors RAID Support NVMe SSD support for RAID 0, RAID 1, RAID 5, and RAID 10
SATA HDD support for RAID 0, RAID 1, RAID 5, and RAID 10 USB
Chipset 1x USB Type-C® port on the rear I/O, supporting USB 3.2 Gen 2x2 Chipset 1x USB Type-C® port, supporting USB 3.2 Gen 2 (requires connection to the internal USB header) Chipset 1x USB 3.2 Gen 2 Type-A port (Red) on the rear I/O Chipset + 2x USB 2.0 Hub 6x USB 3.2 Gen 1 ports (4 on the rear I/O, 2 require connection to the internal USB header) Chipset + 2x USB 2.0 Hub 8x USB 2.0/1.1 ports (4 on the rear I/O, 4 require connection to the internal USB header) Internal Headers & Connectors
Power Connectors 1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
1x 4-pin ATX 12V power connector Fan/Pump Headers 1x CPU fan header
1x Water cooling CPU fan header
3x System fan headers
1x System fan/Water cooling pump header LED Headers 2x Addressable LED strip headers
2x RGB LED strip headers Storage Connectors 3x M.2 connectors
6x SATA 3.0 connectors Front Panel 1x Front panel header
1x Front audio header USB Headers 1x USB Type-C® header, supporting USB 3.2 Gen 2
1x USB 3.2 Gen 1 header
2x USB 2.0/1.1 headers Other Headers 2x Thunderbolt™ add-in card connectors
1x Trusted Platform Module (TPM) header (For GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0)
1x COM port header Buttons & Switches 1x Reset Button
1x Q-Flash Plus Button
1x Clear CMOS Button Other Headers 1x Reset header Rear I/O Ports
USB Ports 1x USB Type-C® port, supporting USB 3.2 Gen 2x2
1x USB 3.2 Gen 2 Type-A port (Red)
4x USB 3.2 Gen 1 ports
4x USB 2.0/1.1 ports Antenna Ports 2x SMA antenna jacks (2T2R) Video Outputs 1x HDMI port
1x DisplayPort Network 1x RJ-45 LAN port Audio 1x Optical S/PDIF Out connector
2x Audio jacks (Supporting 5.1/7.1-channel, configurable in audio software) Hardware Monitoring
Features Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan failure warning
Smart Fan Control / Smart Fan Control (Pump)
* Whether the Smart Fan (Pump) control is supported depends on the cooler you install. BIOS
Features 1x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Utilities & Software
Tools GIGABYTE Control Center (GCC)
* Apps supported by GCC may vary by motherboard model; features of each utility may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup Bundled Software Norton® Internet Security (OEM version)
LAN bandwidth management software Operating System
OS Support Support for Windows 11 64-bit
Support for Windows 10 64-bit Form Factor
PCB Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
