Motherboard chips
Integrated chips
Sound card/network card
Main chipset
Intel H81
Chipset description
Powered by Intel H81 chipset
Display chips
CPU built-in display chip (CPU support required)
Audio chips
Integrated Realtek ALC887 8-channel audio chip
Network card chip
Onboard Intel Gigabit LAN card
Processor specifications
CPU type
Core i7/i5/i3/Pentium/Celeron
CPU socket
LGA 1150
CPU description
Supports Intel 22nm processors
Memory specifications
Memory type
2×DDR3 DIMM
Maximum memory capacity
16GB
Memory description
Supports dual-channel DDR3 1600/1333MHz memory
Storage expansion
PCI-E standard
PCI-E 2.0
PCI-E slots
1× PCIe x16 graphics card slot, 1 × PCIe x1 slot
PCI slots
2 pcs
Storage interfaces
2× SATA III interface, 2× SATA II interface
I/O interface
USB interface
2× USB3.0 interface (backplane), 6× USB2.0 interface (4 built-in + 2 backplane)
Video interface
1× VGA port,1 ×HDMI port
Power connector
One 8-pin, one 24-pin power connector
Other interfaces
1× RJ45 network interface, audio interface, 1×PS/2 mouse, 1×PS/2 keyboard interface
Plate type
Motherboard form factor
Micro ATX form factor
Dimensions
24.4×18.0cm
Software management
BIOS performance
The 2x64Mbit flash
supports DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a using the authorized AMI EFI BIOS
Other parameters
Hardware monitoring
System Voltage Detection,
CPU/System Temperature Detection,
CPU/System Fan Speed Detection,
CPU/System Overtemperature Warning,
CPU/System Fan Fault Warning,
CPU/System Intelligent Fan Control
Other features:
Extreme Memory Profile (XMP) memory is style="text-wrap: wrap;">Payment
