Taoglas RF ANTENNA 2.4GHZ/5.3GHZ Bluetooth, WLAN, Zigbee™ Dome RP-SMA Male Panel Mount AntennaManufacturer Product Number
MA510.C.CG.005The MIMO communication system has been one of the most promising technologies,
well suited for high data rate communication. A MIMO use at least two antenna structures and is more advantageous than single-
input single-output (SISO) in an aspect of increasing channel capacity and reducing
transmitting power. MIMO antennas should have compact structure, high radiation
efficiency, low envelope correlation, and high isolation between the signal ports.
In small structures (antennas spaced closely), the application of MIMO technology has been restricted by high degree of coupling and spatial correlation between antenna elements due to the limited available space. The isolation between antennas become critical as it can deteriorate the system performance and decreases channel capacity.The Hercules MA510 MIMO antenna is low profile, heavy-duty, IP65 waterproof external M2M antenna for use, transportation and remote monitoring applications. This unique omnidirectional antenna provides high efficiency and high isolation between antennas elements in a heavy-duty low profile compact structure, delivering powerful MIMO antenna technology for Wi-Fi® 802.11n and emerging 802.11ac.The antenna screws down permanently onto a roof or metal panel and can be pole or wall-mounted. The two antenna elements are vertically polarized.For industries such as remote monitoring, smart meter systems, construction
equipment, public safety at only 29mm high, the Hercules MA510 MIMO antenna
provides an unobtrusive, robust, rugged antenna that is durable even in extreme
environments.
