Item description
MSI MEG Z590I UNIFY Motherboard Intel Z590 LGA 1200 DDR4 M.2 Mini-ITX Core HDMI
CPU
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® processors 1
Processor socket LGA1200
CHIPSET
Intel® Z590 Chipset
MEMORY
2x DDR4 memory slots, support up to 64GB 1
Supports 1R 2133/2666/2933 MHz for 10th Gen Intel®CPU (by JEDEC & POR)1
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel®CPU (by JEDEC & POR)1
Max overclocking frequency:
1DPC 1R Max speed up to 5600 MHz
1DPC 2R Max speed up to 4800+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile [XMP]
EXPANSION SLOTS
1x PCIe x16 slot
Support up to PCIe 4.0 for 11th Gen Intel® CPU
Support up to PCIe 3.0 for 11th Gen Intel® CPU
ONBOARD GRAPHICS
1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz1/2
1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz1/2
Available only on processors featuring integrated graphics.Graphics specifications may vary depending on the CPU installed.
THUNDERBOLT™ 4
Intel® JHL8540Thunderbolt™ 4 Controller
2x Thunderbolt™ 4 (USB-C) ports on the back panel
Support up to 40Gbps transfer rate with Thunderbolt devices
Support up to 20Gbps transfer rate with USB4 devices
Support up to 10Gbps transfer rate with USB 3.2 devices
Support up to 5V/3A ,15W power charging
Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices
Supports up to 8K display (need to connect the DisplayPort of the discrete graphics card to the Mini DisplayPort Input port on the back panel)
STORAGE
4x SATA 6Gb/s ports (from Z590 chipset)
2x M.2 slots (Key M)
M2_1 slot
Supports up to PCIe 4.0 x4 for 11th Gen Intel® CPU (From CPU)
Supports up to PCIe 3.0 x4 & SATA 6Gb/s for 10th Gen Intel® CPU (From Z590 chipset)
Supports 2280 storage devices
M2_2 slot (from Z590 chipset)
Supports PCIe 3.0 x4 only
Supports 2280 storage devices
Intel® Optane™ Memory Ready1
Supports Intel® Smart Response Technology for Intel Core™ processors
RAID
Intel® Z590 Chipset
Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB
Intel® Z590 Chipset
3x USB 3.2 Gen 2 10Gbps ports (2 Type-A port on the back panel, 1 Type-C internal connector)
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
4x USB 2.0 ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)
AUDIO
Realtek® ALC1220P Codec
7.1-Channel High Definition Audio
WIRELESS LAN & BLUETOOTH
Intel®Wi-Fi 6E AX210
The Wireless module is pre-installed in the M.2 [Key-E] slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz 1(160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.22, FIPS, FISMA
Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in WIN10 21H1.Bluetooth 5.2 will be ready in WIN10 21H1.
INTERNAL CONNECTORS
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x M.2 slots [M-Key]
1x USB 3.2 Gen2 10Gbps Type-C port
1x USB 3.2 Gen1 5Gbps connector [supports additional 2 USB 3.2 Gen1 5Gbps ports]
1x USB 2.0 connector [supports additional 2 USB 2.0 ports]
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1xTPM module connector
BACK PANEL CONNECTORS
DisplayPort
USB 2.0
2.5G LAN
Wi-Fi /Bluetooth
Thunderbolt 4 40Gbps (Type-C)
HD Audio Connectors
Clear CMOS Button
HDMI
USB 3.2 Gen1 5Gbps (Type-A)
USB 3.2 Gen2 10Gbps (Type-A)
Mini DisplayPort Input (for Thunderbolt passthrough)
DIMENSIONS
6.7 in. x 6.7 in. [17.0 cm x 17.0 cm]
Mini-ITX Form Factor
MOUNTING
4 mounting holes
OPERATING SYSTEM
Support for Windows® 10 64-bit
