PCIe x1 Gen 4.0 network card, equipped with the Marvell AQC114 Multi-Gigabit 5G Ethernet controller. It integrates many hardware features intended to optimize performance, including RSS, LSO, checksum offload, Jumbo Frames, Wake-on-LAN, AVB and PTP IEEE 1588 v2.
Compatibility:
PCI Express x1 host interface (compatible x1, x4, x8 and x16).
Operating systems Windows 10 32/64-bit, Windows 11 32/64-bit and Linux Kernel 3.10 or higher.
Technical description:
Marvell AQC114 network controller.
Integrated Ethernet MAC + PHY controller architecture.
PCI Express x1 Gen 4.0 interface, PCI Express Gen4, Gen3 and Gen2 compatible (To take full advantage of 5Gbps Ethernet speed, a PCIe Gen4 x1 link is recommended).
PCIe bus throughput up to 16 GT/s in Gen4, 8 GT/s in Gen3 and 5 GT/s in Gen2, per line.
Network interface 1 RJ45 Multi-Gigabit Ethernet port.
Supported Ethernet speeds 5Gbps / 2.5Gbps / 1Gbps / 100Mbps / 10Mbps.
Transmission distance up to 100 meters for advertised speeds.
Network technologies 5GBASE-T / 2.5GBASE-T / 1000BASE-T / 100BASE-TX / 10BASE-Te.
Recommended cabling Cat5e or higher.
Marvell Alaska PHY with NBASE-T technology.
Energy Efficient Ethernet (EEE) supported.
Jumbo Frames up to 16 KB.
Supported functions: Wake-on-LAN, AVB (Audio Video Bridging), ARP protocol, TCP Keepalive, advanced cable diagnostics.
PTP / IEEE 1588 v2 time synchronization.
LSO, RSS, DCA and Header Checksum optimizations.
Checksum Offload IPv4/IPv6, IPv6/TCP and IPv6/UDP.
PCIe Message-Signaled Interrupts and Legacy INTx.
LED indicators indicate link and network activity.
Standard square format with Low Profile square also supplied.
