SIGN UP NEW Supermicro SYS-E300-12D-8CN6P X12SDV-8C-SP6F Xeon D-1736NT Mini-1U Server Product Description NEW Supermicro SYS-E300-12D-8CN6P X12SDV-8C-SP6F Xeon D-1736NT Mini-1U CTO ServerMini-1U Embedded System with Intel Ice Lake-D CPU with 8 cores Super Server

Manufacturer: Supermicro

Model: SYS-E300-12D-8CN6P

This is a Supermicro SYS-E300-12D-8CN6P Mini-1U server. The box was only opened to remove the factory-installed memory and M.2 drive, power on the system for testing, and update the BIOS and IPMI firmware to the latest available versions.

Current Firmware:
BIOS: 2.2a
IPMI: 1.06.08
IPMI Login: ADMIN / ADMIN

Condition: in box. Fully tested and confirmed working. Memory and M.2 drive have been removed.

What's Included:
Supermicro SYS-E300-12D-8CN6P Server
Original packaging
1x CBL-PWEX-0982 (SATA Power Cable, 1x4F/P2.50 to SATA Power, 25cm)
1x CBL-0473L (SATA Data Cable)
1x Short SFF-8484 to SATA + Molex LP4 Power Cable (from ACC-E300 accessories kit)
Riser cage
Low Profile slot cover
Screws

Note: PCIe riser is NOT included. Memory and M.2 drive are not included.

90-Day Warranty Included!

Key Applications:

• IoT Gateway
• Universal Customer Premise Equipment (uCPE)
• Network Function Virtualization (NFV)
• Networking Security Appliance
• SD-WAN

Key Features:

• Intel Xeon D-1736NT Processor
• 4x DDR4-2933MHz RDIMM (max 256GB) or UDIMM (max 128GB)
• Support for M.2 M/B/E-Key with Nano SIM Card Slot
• Optional PCIe 4.0 x16 Slot (not included)
• 4x 1GbE LAN + 2x 25GbE SFP28 + Dedicated IPMI
• Optional 1x 2.5" drive bay (not included)

Detailed Specifications:

Category Details Motherboard Super X12SDV-8C-SP6F Processor Intel Xeon D-1736NT
Single FCBGA-2227
Up to 8 Cores / 16 Threads
Up to 15MB Cache
Supports up to 67W TDP (Air Cooled) System Memory 4 DIMM slots
Max Memory: Up to 256GB 2933MT/s ECC/non-ECC DDR4 RDIMM/UDIMM
Memory Voltage: 1.2V Network Connectivity 2x SFP28 25GbE
2x RJ45 1GbE (Intel I210-IT)
2x RJ45 1GbE (Intel I350-AM2)
1x RJ45 1GbE Dedicated BMC/IPMI port I/O Ports 2x USB 3.0 Type-A (Rear)
1x VGA (Rear) Expansion 1x PCIe 4.0 x16 Low Profile slot (riser NOT included)
1x M.2 PCIe 3.0 x1 (E-key 2230)
1x M.2 PCIe 3.0 x2 SATA (B-key 2280/3042/3052)
1x M.2 PCIe 3.0 x4 NVMe/SATA (M-key 2280) Storage 1x Internal fixed 2.5" SATA drive bay (optional / NOT included) System Cooling 2x 40x40x28mm 4-pin PWM fans included Power Supply 1x 180W Power Supply
Input: 100-240Vac / 47-63Hz Dimensions Height: 1.69" (43mm)
Width: 10.43" (264.8mm)
Depth: 8.89" (225.8mm)
Net Weight: 3.7 lbs (1.6 kg) Operating Environment Operating Temperature: 0C to 40C (32F to 104F)
Non-operating Temperature: -40C to 70C (-40F to 158F) Security Features TPM 2.0
Silicon Root of Trust (NIST 800-193 Compliant)
Secure Boot, Secure Firmware Updates, System Lockdown

Parts List (What is Actually Included):

Category Part Number Qty Description Motherboard / Chassis MBD-X12SDV-8C-SP6F
CSE-E300 1
1 Super X12SDV-8C-SP6F Motherboard
Mini-1U Chassis Power Cable CBL-PWEX-0982 1 SATA Power Cable (1x4F/P2.50 to SATA Power, 25cm) Data Cable CBL-0473L 1 SATA Data Cable Power/Data Cable 1 Short SFF-8484 to SATA + Molex Power Cable (from ACC-E300 kit) FAN FAN-0100L4 2 40x28mm 4-Pin PWM Fan Power Supply MCP-250-10133-0N 1 180W AC-DC Lockable Power Adapter with US Power Cord Accessories 1 Riser cage + LP slot cover + Screws

Not Included:
PCIe Riser
Memory
M.2 Drive
2.5" Drive
