HPE JG936A Overview

HPE FlexNetwork 5130 EI Series switches are fully managed enterprise class Gigabit switches supporting Layer 3 static routing and RIP routing, IRF stacking up to nine units high, with four built in 10 Gigabit links. This JG936A has 24 x 10/100/1000 PoE+ enabled ports plus four SFP+ ports for high speed 10 Gigabit or Gigabit fiber connections using optional transceivers.

Quick Spec

Product Code

JG936A

Type

HPE FlexNetwork 5130-24G-PoE+-4SFP+ (370W) EI Switch

I/O ports and slots

24 x RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX,

IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 x SFP+ fixed 1000/10000 SFP+ ports

Additional ports and slots

1 x RJ-45 serial console port

Memory and processor

1 GB SDRAM
512 MB flash
packet buffer size: 1.5 MB

Reliability

MTBF (years): 48.3

PoE power

370 W PoE+

Maximum power rating

460 W

Dimensions

4.37 x 44 x 30 cm (1.72 x 17.32 x 11.81 in)

Weight

8 kg (17.64 lb)
