Mellanox MCP1600-E005E26 5M 100Gb/s QSFP28 Passive Direct Attach Copper Cable

The Mellanox MCP1600-E005E26 is a high-speed 100Gb/s QSFP28 passive Direct Attach Copper (DAC) cable designed for short-distance, high-bandwidth connectivity in data center and high-performance computing environments.

This cable features QSFP28 connectors on both ends, a 5-meter length, and 26AWG copper construction. It is designed for InfiniBand EDR connectivity up to 100Gb/s and provides a cost-effective, low-power solution for connecting compatible high-speed networking equipment.

• Brand: Mellanox / NVIDIA
• Part Number: MCP1600-E005E26
• Cable Type: Passive Direct Attach Copper (DAC)
• Data Rate: Up to 100Gb/s
• Length: 5 Meters / 16.4 Feet
• Connector: QSFP28 to QSFP28
• Wire Gauge: 26AWG
• Technology: InfiniBand EDR
• Cable Color: Black
• LSZH Jacket
• Hot-Pluggable QSFP28 Connectors
• Low-Power Passive Design
• RoHS Compliant
• SFF-8665 QSFP28 Interface
• SFF-8636 I2C Management Interface

• Cable Length: 5m
• Data Rate: Up to 100Gb/s
• AWG: 26
• Cable Diameter: 9.4 ± 0.4mm
• Minimum Single Bend Radius: 47mm
• Minimum Repetitive/Assembly Bend Radius: 94mm
• Operating Temperature: 0°C to 70°C
• Connector: QSFP28 to QSFP28
• Media: Copper
• Cable Type: Passive DAC

• NVIDIA Mellanox InfiniBand EDR Networks
• High-Performance Computing (HPC)
• AI and GPU Clusters
• Data Centers
• Server-to-Switch Connectivity
• Switch-to-Switch Connectivity
• Top-of-Rack (ToR) Networking
• High-Bandwidth Enterprise Networks
• Short-Distance 100Gb/s Interconnects

• 1 × Mellanox MCP1600-E005E26 5M 100Gb/s QSFP28 Passive DAC Cable

Condition: New
