This industrial-grade 30W PoE media converter features agigabit Ethernet port and an SFP slot, delivering reliable network connectivityin extreme outdoor conditions. Its plug-and-play design supports a wide voltageinput range and allows flexible installation on DIN rails or walls.

Key Features

• Dual Port Configuration: Includes one 10/100/1000BASE-T RJ45 port with auto MDI/MDI-X and one SFP port supporting 100Base-FX or 1000Base-X dual mode with auto detection.

• Industrial Grade Quality: Built with industrial components and an aluminum housing, it can operate in temperatures ranging from -40°C to 75°C (-40°F to 167°F).

• Plug & Play: Works immediately when connected; no configuration required. Supports IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab, and IEEE802.3x standards.

• Flexible Mounting Options: Comes with accessories for DIN rail or wall mounting.

• Wide Voltage Support: Accepts DC input from 12V to 48V, compatible with various power supplies including solar setups.

Additional Details

• Brand: Meixingtong
• Model Number: 1 RJ45+1 SFP 30W
• Connector: 1 x RJ45
• Optical Port: 1 x SFP 1000Base-X or 100Base-FX (auto detection)
• Input Power: 12~48VDC, 4-pin terminal block
• Power Consumption: 36W Max
• Country of Origin: China

Quarter in photo used for scale.
