64GB Half Slim SATA 6Gbps MO-297 SSD for Embedded Industrial CNC POS Medical Slot Machines
This is a 64GB Half-Slim SATA SSD built to the JEDEC MO-297 form factor (also commonly called Half-Slim / Slim SATA MO-297). These compact SSD modules are widely used in space-limited systems where a full 2.5" drive will not fit, including industrial automation, CNC/PLC controllers, robotics, casino/slot machines, arcade systems, kiosks/POS terminals, medical equipment, embedded PCs, and select enterprise platforms that support MO-297 Half-Slim SATA storage.
It connects through a standard SATA (7+15 pin) interface and typically supports SATA III 6Gb/s (backwards compatible with SATA II/I). Controller, NAND type (MLC/TLC), endurance features, and temperature rating can vary by exact model/part number, but all listed equivalents share the same 64GB capacity and MO-297 Half-Slim SATA physical/interface standard.
Technical Specifications
- Capacity: 64GB
- Form Factor: Half-Slim SATA (JEDEC MO-297)
- Interface: SATA III 6Gb/s (backwards compatible with SATA II/I)
- Connector: 7+15 pin SATA
- Typical Module Dimensions: 54.0 mm x 39.8 mm x ~4 mm (clearance varies by design)
- Flash Type (varies by model): MLC / 3D TLC / SLC / pSLC depending on the specific part number
- Typical Operating Voltage: 3.3V (host/platform dependent)
- Common Reliability Features (model dependent): Wear leveling, ECC, SMART, TRIM, block management, power-saving modes
