Siemon HD6-24 24-Port Flat High Density Category 6 Patch Panel

New... Opened for pictures.

Features

• Universal Wiring HD 6 Patch Panels feature universal wiring for both T568A and T568B
• Installer Friendly Black anodized panels can be mounted directly to an EIA standard 19 inch relay rack or cabinet
• Aesthetics Front surface is uninterrupted by screw heads for a clean appearance
• Quick Identification Icon label holders and designation labels included

Specification Description

110-Modular Patch Panel
Type: Flat
Number Of Ports: 24
Rack Mount Space: 1
Contact Resistance: 20 mOhm
Input To Output Resistance: 200 mOhm
Minimum Dielectric Withstand Voltage (Contact To Contact): 1000 Volt DC Or AC Peak
Minimum Dielectric Withstand Voltage (Contact To Shield): 1500 Volt DC Or AC Peak
Insulation Resistance: 500 MOhm
Compatibility: Backwards to 5e And Cat 3
Current Rating: 1.5 AnPoE And PoE And PoE+
Operating Temperature: -10 to 60 deg C (14 to 140 deg F)
Jack Housing Material: Glass-Reinforced Nylon
Jack Contact Material: Plated Phosphor Bronze, Stainless Steel
Jack Plastic Material: Flame Retardant Thermoplastic
Number Of Plug Insertion Cycles: 750
Minimum Plug Retention Force: 50 N
Nominal Wire Size Range: 23-26 AWG Solid And Stranded
Maximum Wire Insulation Diameter Range: 1.48 mm (0.058 Inch)
Maximum Conductor OD: 0.6 mm (0.023 Inch)
Maximum Cable OD: 9 mm (0.354 Inch)
Reterminations: 20
Wiring: T568A/T568B
