4 x 5.25" expansion bays for optical drives, hot-swap cages, and other front-access devices
Supports 180mm front fans for exceptional airflow performance
Supports versatile storage options including 5.25", 3.5", and 2.5" devices
Supports 360mm radiators
Supports graphics cards up to 413mm in length and includes a dedicated GPU support bracket
Front I/O ports include: 1 × USB Type-C, 2 × USB 3.0, 1 × audio, and 1 × microphone
Model Mini-ITX
Drive bay
External
5.25" x 4
Internal
3.5" x 1
3.5" x 1/2.5" x 2
Cooling system
Front
180mm x 1 (180mm black fan x 1 included) /140mm/120mm
*Please ensure compatibility between 5.25" devices and cooling components before installing 120mm / 140mm fans
Rear
120 x 1 (120mm black fan x 1 included)
Top
120mm x 3 / 140mm x 2
*Please ensure compatibility between 5.25" devices and cooling components before installing more than two fans
Internal
PSU Chamber: 120mm x 2
*Only one 120mm fan can be installed when the GPU support bracket is mounted at the rear position
Radiator support
Front
120mm / 140mm / 240mm / 280mm
*Please ensure compatibility between 5.25" devices and cooling components before / 140mm / 240mm / 280mm / 360mm
*Please ensure compatibility between 5.25" devices and cooling components before installation
Limitation of CPU cooler
155mm (with GPU brace installed)
169mm (without GPU brace installed)
Expansion slot
5
Limitation of expansion refer to manual for GPU and front fan or radiator compatibility
Width
156mm (with GPU brace installed)
163mm (without GPU brace installed)
Power supply
PS2 (ATX)
Limitation of PSU
180mm (with bottom drive cage in rear position)
200mm (with bottom drive cage in front position)
Front I/O port
USB Type-C x 1
USB 3.0 x 2
Audio x 1
Microphone x 1
Dimension
220mm (W) x 456.3mm (H) x 483.6mm (D), 48.5 Liters
8.66" (W) x 17.96" (H) x 19.04" (D), 48.5 Liters
