Key Features - Embedded Networking Applications
- Network Security Appliance
- FireWall Applications
- Virtualization Server
1. Intel® Xeon® processor D-1518,
Single socket FCBGA 1667;
4-Core, 8 Threads, 35W2. System on Chip3. 1x 2.5" fixed drive bay with
bracket (when AOC area is not occupied)4. Up to 128GB ECC RDIMM DDR4
2133MHz or 64GB ECC/non-ECC
UDIMM in 4 sockets5. 1 PCI-E 3.0 x8 AOC slot (LP),
Mini PCI-E (mSATA support),
M.2 PCI-E 3.0 x4 (SATA support),
M Key 2242/2280/221106. 2x 10G SFP+, 6 GbE LAN, and
dedicated LAN for IPMI 2.07. VGA via BMC, 2 USB 3.0 ports8. Passive CPU heat sink and
2x 40mm chassis fans 9. DC power adapter
