Series AX SeriesCase Type Full TowerDimensions 550 x 248 x 548 mm (21.7 x 9.8 x 21.6 inch)Side Panel Steel + TGColor BLACKMaterial SPCCCooling System 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 4Drive Bays 5 x 3.5” , 1 x 2.5” or 6 x 2.5”Expansion Slots 8Motherboard 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) ,12” x 13” (E-ATX), SSI-CEB, SSI-EEB
Hidden-Connector Motherboard9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)I/O Port USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1PSU Standard PS2 PSU (optional)Fan Support Front:4 x 120mm ,3x 120mm , 2x 120mm , 1x 120mm3 x 140mm , 2x 140mm , 1x 140mmTop:3 x 120mm , 2x 120mm , 1x 120mm3 x 140mm , 2x 140mm , 1x 140mmRear:1 x 120mm , 1 x 140mmRight:3 x 120mm , 2x 120mm , 1x 120mm2 x 140mm , 1x 140mmPower Cover:3 x 120mm , 2x 120mm , 1x 120mmRadiator Support Front (AIO):1 x 360mm, 1 x 240mm, 1 x 120mm1 x 420mm, 1 x 280mm, 1 x 140mmTop (AIO):1 x 360mm, 1 x 240mm, 1 x 120mm1 x 420mm, 1 x 280mm, 1 x 140mmRear(AIO):1 x 120mm , 1 x 140mmClearance CPU cooler height limitation: 185mm(Max) VGA length limitation:460mm(Max) PSU length limitation: 200mm (Max)
