High-capacity 60 GHz radio that supports long-distance PtP (bridge) and PtMP links.
Dimensions⌀424.4 x 166.2 mm(⌀16.7 x 6.5")WeightWithout mount: 2.8 kg (6.2 lb)With mount: 4 kg (8.8 lb)Enclosure MaterialAluminum alloy, UV stabilized polycarbonateMount MaterialStainless steelPole Mount Diameter25 to 76.2 mm (1 to 3")Wind Loading369 N at 200 km/h (83 lbf at 125 ARM® Cortex®-A53 at 1.4 GHzMemory512 MBNetworking Interface(2) 2.5 GbE RJ45 ports(1) 10G SFP+ portMax. Power Consumption26WPower MethodPassive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC onlySupported Voltage Range44–54V DC22–27V DCPower Supply48V DC, 0.65A, 2.5 GbE PoE adapter (Included)GPS✓Buttons(1) Factory resetLEDsPowerFlashing white: bootup in progressWhite: not connected to UISP applicationBlue: connected to UISP applicationFlashing blue: locate in progressBlue/white: firmware upgrade in progressEthernet(2) Flashing blue: Ethernet traffic detectedGPSBlue: receiving at least (4) GPS satellite signalLinkWhite: 5 GHz linkBlue: 60 GHz linkSFP+(1) Flashing blue: SFP+ traffic detectedAmbient Operating Temperature-40 to 60° C (-40 to 140° F)Ambient Operating Humidity5 to 95% noncondensingNDAA Compliant✓CertificationsFCC, IC, CESoftwareOperating ModesPtPPtMP StationUbiquiti Specific FeaturesDiscovery Protocol✓Traffic Shaping with Burst Support✓ServicesUISP✓Ping Watchdog✓NTP Client✓SNMP✓ToolsCable Test✓Wave AI✓Wave Technology✓UtilitiesAntenna Alignment✓Ping✓Site Survey✓Speed Test✓Traceroute✓Discovery Utility✓NetworkBridge/Router modeApplication RequirementsUISPVersion 2.3.0 and laterSystemTotal Throughput5.4 GbpsMax. RangePtP: Up to 15 km (9.3 miles)PtMP: Up to 8 km (5 miles) (Wave AP), up to 6 km (3.7 miles) (Wave AP Micro, Wave AP Gen2)EncryptionWPA2-PSK (AES)Radio FrequencyOperating FrequencyWorldwide57–71 GHzChannel Bandwidth2160, 1080, 540 MHzOperating Channels58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200, 70560 MHzModulation16QAM, QPSKAntenna Gain46 3 dB 1.3°Elevation: 3 dB 1.3°Radio Frequency (Back-Up)WiFi Standard802.11ax (WiFi 6)Operating FrequencyUS/CAU-NII-1 5150 - 5250 MHzU-NII-2A 5250 - 5350 MHzU-NII-2C 5470 - 5725 MHzU-NII-3 5725 - 5850 MHzWorldwide5150 - 5875 MHzChannel Bandwidth20, 40, 80 MHzModulationBPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)Antenna Gain22 3 dB 8°Elevation: 3 dB 8°Cross-Pol Isolation20 dBElectrical Downtilt0°
