Motherboard chips

Integrated chips

Sound card/network card

Main chipset

Intel B560

Chipset description

Powered by Intel B560 chipset

Display chips

CPU built-in display chip (CPU support required)

Audio chips

Integrated Realtek ALC897 7.1-channel audio chip

Network card chip

Onboard Intel I219V Gigabit LAN card

Processor specifications

CPU type

11th Gen/10th Gen Core/Pentium/Celeron

CPU socket

LGA 1200

CPU description

Turbo Boost Max 3.0 technology

Memory specifications

Memory type

2×DDR4 DIMM

Maximum memory capacity

64GB

Memory description

Dual-channel DDR4 5000MHz (OC) memory
support Intel Extreme Memory Profile (XMP) 2.0 technology

Storage expansion

PCI-E standard

PCI-E 4.0

PCIe x16 slot

1 pc

PCIe x1 slot

2 pc

Storage interfaces

2× M.2 interface, 4× SATA III interface

I/O interface

USB interface

6× USB3.2 Gen1 interface, 6× USB2.0 interface

Video interface

1× VGAinterface, 1 ×DVIinterface,1 × HDMI interface

Power connector

One 8-pin, one 24-pin power connector

Other interfaces

1× PS/2 keyboard/mouse interface, 1×RJ-45 network card interface, 3 × audio interface

Plate type

Motherboard form factor

Micro ATX form factor

Dimensions

Software management

BIOS performance

Multi-Chinese 128Mb AMI UEFI Legal BIOS
Compatible with ACPI 6.0 Compatible Wake-up Event
Support SMBIOS 2.7
CPU core/cache, GT, RAM, VPPM, VCCIN_AUX, VCCST, VCCSA voltage multi-function regulator

Other parameters

Power supply mode

6 phases

Overclocking function

In the tank

Hardware monitoring

Fan Tachometer: CPU, CPU/Water Pump, Case/Water Pump Fan
Silent Fan (Automatically adjusts case fan speed based on processor temperature): CPU, CPU/WATER PUMP, Case/Water Pump Fan Fan Multi-Speed Control: CPU, CPU/Water Pump, Case/Water Pump Fan

Chassis on detection
Real-time voltage monitoring: +12V, +5V, +3.3V, CPU cores, DRAM, VPPM, VCCIN_AUX, VCCSA, VCCST, ATX_5VSB

Other features:

Motherboard Tuning Software (A-Tuning)

Extreme Network EZ Mode
Full HD UEFI Custom UEFI

Instant Flash Cloud Method
