please make sure this item is the correct one your wanted before purshasing.

Motherboard Description:

CPU

Intel ® Socket 1150 for the 4th generation Core ™ i7 / Core ™ i5 / Core ™ i3 / Pentium® / Celeron®

Supports Intel ® 22nm CPU

Supports Intel ® Turbo Boost Technology 2.0

* The support of Intel® Turbo Boost Technology 2.0 depends on the types of CPU.

* See ASUS official website for the list of CPU support

Chipset

Intel ® H81

Memory

2 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory

Dual Channel memory architecture

Supports Intel Extreme Memory Profile ® (XMP)

* Hyper DIMM support is subject to the physical characteristics of each CPU.

* See ASUS official website for QVL memory (qualified vendors).

* Due to the limitations of the Intel ® chipset, 1600 MHz DDR3 and higher memory modules in the XMP mode will operate at the maximum transfer rate of 1600 Mhz DDR3.

Graphic

Integrated Graphics Processor

Multi-support VGA output: DVI / RGB ports

Supports DVI with max. Resolution 1920 x 1200 at 60 Hz

RGB compatible with max. Resolution 1920 x 1200 at 60 Hz

Maximum shared memory of 1024 MB

Supports Intel® InTru ™ 3D, Quick Sync Video, Clear Video HD Technology, Insider

Expansion Slots

1 x PCIe x16

2 x PCIe 2.0 x1

Storage

2 x SATA 6Gb / s port (s), yellow

2 x SATA 3Gb / s port (s), dark brown

Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology * 1

LAN

Realtek ® 8111G, 1 x controlador Gigabit LAN (s)

Audio

Realtek ® ALC887 8 channels High Definition Audio CODEC * 2

Compatible with: Jack-detection, Front Panel Jack-reassignment of tasks

USB Ports

Intel ® H81 Chipset: 2 x USB 3.0 / 2.0 (s) port (2 on the back panel, blue) Intel H81 ® Chipset: 6 x USB 2.0 (s) ports (2 on the back panel, black, 4 on the board )

ASUS EPU

ASUS EPU Exclusive features: - Boost GPU - AI Suite 3 - Ai charger - Anti-Surge - ASUS UEFI BIOS EZ Mode with user friendly graphical user interface - iControl Network - USB 3.0 Boost - ASUS Quiet Thermal Solution Unlocker Disk: - Elegant Design without fan heat sink solution - ASUS Fan Xpert ASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 ASUS Q-Design: - ASUS Q-Slot

operating systems

Windows ® 8

Windows ® 7

Back I/O Ports

1 x teclado PS / 2 (violeta)

1 x PS / 2 ratón (verde)

1 x DVI

1 x D-Sub

1 x puerto LAN (RJ45) (s)

2 x USB 3.0 (azul)

2,0 2 x USB

3 x Audio jack (s)

Internal I/O Ports

2 USB 2.0 (s) support connectors additional port 4 USB 2.0 (s)

2 x SATA 6Gb / s Connector (s)

2 x SATA 3Gb / s Connector (s)

1 x CPU fan connector (s) (1 x 4-pin)

1 x chassis fan connector (s) (1 x 4-pin)

1 x S / PDIF header out (s)

1 x 24-pin EATX power connector (s)

1 x 4-pin ATX 12V power connector (s)

1 x front panel connector (s)

1 x front panel audio connector (s) (AAFP)

1 x internal speaker connector (s)

1 x Clear CMOS jumper (s)

BIOS

64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, BIOS in several languages, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, quick note, updated log, F12 PrintScreen, F3 shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information

Manageability

WfM 2.0, DMI 2.0, WOL por PME, PXE

Form Factor

uATX form factor

8.9 inches x 6.9 inches (22.6 cm x 17.5 cm)

Instructions:

• Please DO NOT use fake memory, because the motherboard maybe can't support.

• Please DO NOT use single-side memory, because some motherboards can't support.

• Some CPUs can't be supported by motherboard, please try to update the BIOS, please note that's not motherboard's defect.


• Some "Can't boot" problem's caused by memory, please clean the memory's gold fingers and clean the motherboard's memory solts.


Package Included:

• 1 * motherboard

• 2 * sata cable

• 1 x I/O back panel
