Key Applications• Centralized/Cloud Radio Access
Network (C-RAN)
• Universal Customer Premise
Equipment (uCPE)
• Software Defined WAN (SD-WAN)
• Network Function Virtualization
(NFV)Key Features1. Intel® Xeon® D-2146NT Processor,
8-Core, 16 Threads, 2.3 GHz, 80W2. Up to 512GB ECC LRDIMM,
up to 256GB reg. ECC RDIMM
DDR4-2133Mz; in 4 DIMM slots3. 4 PCI-E 3.0 x8 slots for optional AIOM4. 2x 2.5" drive bays (one drive space
shares with M.2), 2 E1.S
(40°C ambient temperature only)5. M.2 Slots:
2 M-Keys 2242/80/110 (PCI-E 3.0 x4/SATA)
(space shared with one 2.5" drive bay),
1 B-Key 3042 (PCI-E 3.0 x4/SATA)
1 E-Key 2230 (PCI-E 3.0 x2)6. 2x 10GbE (shared with IPMI), 2x 10G
SFP+, 1 Ethernet Management port7. 2 USB 3.0, 1 VGA,
1 COM via RJ45 or Micro USB8. 400W Redundant Platinum Level
Power Supplies
